SKU: CX4543-3784  |   Brand: Socket Mobile

Socket Mobile XtremeScan Mag 662 Handheld bar code reader 1D/2D LED Black, Green

SKU: CX4543-3784  |   Brand: Socket Mobile

Socket Mobile XtremeScan Mag 662 Handheld bar code reader 1D/2D LED Black, Green

0 in stock

£580.55 ex. VAT

Figures are exclusive of VAT.



The XtremeScan Mag 662 delivers industrial-grade scanning performance in a compact Bring-Your-Own-Device (BYOD) design. Featuring a secure magnetic mounting system, the 662 enables workers to attach and detach their mobile device with ease while maintaining reliable mid-range 1D/2D barcode capture up to 14 feet away.

Built for field mobility and industrial reliability, the XtremeScan 662 combines a rugged mid-range barcode scanner with Socket Mobile’s magnetic attachment system to create a powerful and flexible scanning solution. Ideal for warehousing, logistics, and field service teams, the 662 allows professionals to capture barcodes on shelves, pallets, or equipment with precision and speed while reducing downtime and increasing productivity.

With IP67-rated protection against dust, water, and rough handling, the 662 withstands the challenges of daily industrial use. The magnetic mounting system allows workers to easily switch between scanning and other mobile tasks while keeping their device secure. Bluetooth® LE connectivity ensures quick pairing, extended battery life, and consistent performance with iOS, Android, and Windows devices.

Type Handheld bar code reader
Scanner type 1D/2D
Bluetooth Y
Sensor type LED
Connectivity technology Wireless
Standard interfaces Bluetooth

Scanning
TypeHandheld bar code reader
Linear (1D) barcodes supportedCodabar, Code 128, Code 93, Code 39, EAN-8, EAN-13, JAN-13, JAN-8, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, Interleaved 2 of 5, ISBT 128, Trioptic, UPC-A, UPC-E
2D (matrix & stacked) barcodes supportedAztec Code, Composite Codes, Data Matrix, DotCode, Grid Matrix Code, Han Xin, MaxiCode, MicroPDF417, Micro QR Code, PDF417, QR Code
Tilt reading angle33.5 - 44.5°
Sensor typeLED
Scanner type1D/2D
Light levels (direct sunlight)0 - 100000 lx
Optical sensor resolution (W x H)1280 x 960 pixels
Ports & interfaces
Wireless range10 m
Connectivity technologyWireless
Bluetooth version2.1+EDR
BluetoothYes
Standard interfacesBluetooth
Performance
LED indicatorsYes
International Protection (IP) codeIP67
Product colourBlack, Green
Country of originChina
Print contrast25%
Light levels (direct sunlight)0 - 100000 lx
Design
TypeHandheld bar code reader
LED indicatorsYes
International Protection (IP) codeIP67
Product colourBlack, Green
Power
Power source typeBattery, USB
Charging time7 h
Battery voltage3.7 V
Battery technologyLithium-Ion (Li-Ion)
Battery capacity1200 mAh
Charging port typeUSB Type-C
Weight & dimensions
Width91 mm
Depth91 mm
Height193.1 mm
Technical details
TypeHandheld bar code reader
LED indicatorsYes
Windows operating systems supportedYes
Mobile operating systems supportedAndroid, iOS
International Protection (IP) codeIP67
Product colourBlack, Green
Warranty period1 year(s)
Compliance certificatesCE, Federal Communications Commission (FCC), UKCA, UL, RoHS
Operational conditions
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 60%
Light levels (direct sunlight)0 - 100000 lx
Battery
Battery weight22 g
Battery capacity4.44 Wh
Rechargeable batteryYes
Number of battery cells1
Other features
Windows operating systems supportedYes
Mobile operating systems supportedAndroid, iOS
