SKU: CX4180-3247  |   Brand: Socket Mobile

Socket Mobile XtremeScan XS930 Handheld bar code reader 1D Laser Black, Green

SKU: CX4180-3247  |   Brand: Socket Mobile

Socket Mobile XtremeScan XS930 Handheld bar code reader 1D Laser Black, Green

0 in stock

£460.98 ex. VAT

Figures are exclusive of VAT.



The XtremeScan XS930 is a modular, rugged, handheld mobile data reader that combines an iPhone case and 1D laser barcode reader to form a one-handed, industrial-grade scanning solution. It features long-range scanning capability, making it ideal for applications scanning barcodes on floor labels and rack labels on high shelves. The scanner is integrated with a heavy-duty case and is designed to withstand heavy use in demanding industrial environments. The XtremeScan case provides IP67-sealed housing and protects against jets of low-pressure water. It includes an integrated wireless charger, so you can charge the iPhone without removing it from the case.

With a compatible iPhone, the XtremeScan XS930 laser barcode scanner becomes a versatile and powerful mobile solution that can be used with a variety of industrial applications. The XS930 has a class 2 laser that scans through plastic or glass, in bright or poor lighting conditions, sideways, upside down, or straight at imperfect barcodes. Depending on the barcode symbology, width, size, and label media, the XS930 can scan from 1.2 inches (3.0 cm) to 180 inches (457.2 cm). The industrial-grade, rugged housing can handle multiple drops onto concrete.

Standard interfaces Bluetooth
Scanner type 1D
Bluetooth Y
Power source type Battery
Connectivity technology Wireless
Sensor type Laser
Type Handheld bar code reader
2D (matrix & stacked) barcodes supported Not supported

Scanning
TypeHandheld bar code reader
Linear (1D) barcodes supportedCodabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, JAN-13, JAN-8, GS1 DataBar Expanded, GS1-128 (UCC/EAN-128), GS1 Databar Limited, GS1 DataBar Omnidirectional, ISBT 128, Interleaved 2 of 5, Trioptic, UPC-A, UPC-E
2D (matrix & stacked) barcodes supportedNot supported
Tilt reading angle10 - 47°
Sensor typeLaser
Scanner type1D
Light levels (direct sunlight)0 - 100000 lx
Ports & interfaces
Wireless range10 m
Connectivity technologyWireless
Bluetooth version2.1+EDR
BluetoothYes
Standard interfacesBluetooth
Performance
Protection featuresDrop proof
LED indicatorsYes
Housing materialPlastic, Glass
International Protection (IP) codeIP67
Product colourBlack, Green
CertificationUN3481, P.I. 967
Country of originChina
Print contrast25%
Light levels (direct sunlight)0 - 100000 lx
Design
TypeHandheld bar code reader
Protection featuresDrop proof
LED indicatorsYes
Housing materialPlastic, Glass
International Protection (IP) codeIP67
Product colourBlack, Green
CertificationUN3481, P.I. 967
Power
Power source typeBattery
Battery life25 h
Charging time8 h
Battery voltage3.7 V
Number of reads per charge500
Battery technologyLithium-Ion (Li-Ion)
Battery capacity700 mAh
Weight & dimensions
Width91 mm
Depth44.5 mm
Height193.1 mm
Technical details
TypeHandheld bar code reader
Protection featuresDrop proof
LED indicatorsYes
Housing materialPlastic, Glass
Mobile operating systems supportedAndroid, iOS
International Protection (IP) codeIP67
Product colourBlack, Green
CertificationUN3481, P.I. 967
Compliance certificatesRoHS, Federal Communications Commission (FCC), CE, UKCA
Operational conditions
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 60%
Light levels (direct sunlight)0 - 100000 lx
Battery
Battery weight12.5 g
Battery capacity2.59 Wh
Rechargeable batteryYes
Number of battery cells1
Other features
Mobile operating systems supportedAndroid, iOS
