| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| Microphone in | No |
| Headphone outputs | 0 |
| Connectivity technology | Wired |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 85 W |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Network |
|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance |
|---|
| Number of displays supported | 1 |
| Country of origin | Taiwan |
| Product colour | Silver |
| Card reader integrated | No |
| Compatibility | Available USB-C® port that supports DisplayPort™ alternate mode and USB™ Power Delivery 2.0 or 3.0. |
| Plug and Play | Yes |
| Data transfer rate | 5 Gbit/s |
| Certification | Works with Chromebook |
| Housing material | Aluminium |
| Display modes | Extended, Mirror, Primary display |
| Maximum refresh rate | 60 Hz |
| Technical details |
|---|
| Product colour | Silver |
| Compatibility | Available USB-C® port that supports DisplayPort™ alternate mode and USB™ Power Delivery 2.0 or 3.0. |
| Plug and Play | Yes |
| Data transfer rate | 5 Gbit/s |
| Master (outer) case GTIN (EAN/UPC) | 24712795086373 |
| Warranty period | 2 year(s) |
| Special features | Chromebook™ Certified, 5-in-1 Functions, 86W of Pass-Through Charging |
| Products per master (outer) case | 24 pc(s) |
| Master (outer) case width | 230 mm |
| Master (outer) case gross weight | 3.88 kg |
| Master (outer) case length | 435 mm |
| Master (outer) case height | 190 mm |
| Products per shipping (inner) case | 6 pc(s) |
| Storage |
|---|
| Card reader integrated | No |
| Power |
|---|
| Power consumption (typical) | 2 W |
| Output voltage | 20 V |
| Output current | 0.4 A |
| USB cable length | 0.2 m |
| Software |
|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Other operating systems supported | ChromeOS |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -17 - 68 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage relative humidity (H-H) | 0 - 85% |
| Weight & dimensions |
|---|
| Weight | 74.8 g |
| Width | 66.5 mm |
| Depth | 14.7 mm |
| Height | 77.6 mm |
| Package weight | 129 g |
| Package width | 155 mm |
| Package depth | 95 mm |
| Package height | 30.8 mm |
| Design |
|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Country of origin | Taiwan |
| Product colour | Silver |
| Certification | Works with Chromebook |
| Packaging data |
|---|
| Quantity per pack | 1 pc(s) |
| Package weight | 129 g |
| Package width | 155 mm |
| Package depth | 95 mm |
| Package height | 30.8 mm |
| Packaging content |
|---|
| Quick start guide | Yes |
| Manual | Yes |
| Cables included | USB Type-C |
| Quantity per pack | 1 pc(s) |
| Certificates |
|---|
| Certification | Works with Chromebook |
| Logistics data |
|---|
| Shipping (inner) case width | 10.3 cm |
| Shipping (inner) case length | 21.8 cm |
| Shipping (inner) case height | 16.5 cm |
| Shipping (inner) case net weight | 870 g |
| Products per master (outer) case | 24 pc(s) |
| Master (outer) case width | 230 mm |
| Master (outer) case gross weight | 3.88 kg |
| Master (outer) case length | 435 mm |
| Master (outer) case height | 190 mm |
| Products per shipping (inner) case | 6 pc(s) |
| Export Control Classification Number (ECCN) | EAR99 |
| Other features |
|---|
| Special features | Chromebook™ Certified, 5-in-1 Functions, 86W of Pass-Through Charging |
