| Design |
|---|
| Product type | Mobile workstation |
| Market positioning | Business |
| Form factor | Clamshell |
| Product colour | Grey |
| Country of origin | Indonesia |
| Intel® vPro™ Platform Eligibility | Yes |
| Introduction year | 2022 |
| Display |
|---|
| HD type | Quad HD+ |
| Pixel density | 216 ppi |
| Panel type | WLED |
| LED backlight | Yes |
| Display brightness | 500 cd/m² |
| Display response rise/fall | 35 ms |
| Pixel pitch | 0.1178 x 0.1178 mm |
| Contrast ratio (typical) | 1000:1 |
| Touchscreen | Yes |
| Display resolution | 2560 x 1600 pixels |
| Display diagonal | 35.6 cm (14") |
| Maximum refresh rate | 60 Hz |
| RGB colour space | sRGB |
| Colour gamut | 100% |
| Native aspect ratio | 16:10 |
| Processor |
|---|
| Processor generation | 12th gen Intel® Core™ i9 |
| Configurable TDP-down | 35 W |
| Processor cache | 24 MB |
| Processor model | i9-12900H |
| Processor boost frequency | 5 GHz |
| Processor cores | 14 |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i9 |
| Memory |
|---|
| Memory form factor | On-board |
| Internal memory | 32 GB |
| Internal memory type | LPDDR5-SDRAM |
| Memory clock speed | 5200 MHz |
| Maximum internal memory | 32 GB |
| Storage |
|---|
| SSD form factor | M.2 |
| Storage media | SSD |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| Card reader integrated | Yes |
| Compatible memory cards | SDXC, SD, SDHC |
| Total storage capacity | 1 TB |
| Total SSDs capacity | 1 TB |
| NVMe | Yes |
| Graphics |
|---|
| Discrete graphics card | Yes |
| Discrete graphics card memory | 4 GB |
| On-board graphics card | Yes |
| On-board graphics card model | Intel Iris Xe Graphics |
| Discrete graphics card model | NVIDIA RTX A1000 |
| Discrete graphics memory type | GDDR6 |
| Discrete GPU manufacturer | NVIDIA |
| On-board GPU manufacturer | Intel |
| Audio |
|---|
| Audio chip | Realtek ALC711-VD |
| Number of microphones | 2 |
| Number of built-in speakers | 4 |
| Speaker power | 8 W |
| Built-in subwoofer | Yes |
| Built-in microphone | Yes |
| Camera |
|---|
| Front camera | Yes |
| Front camera resolution (numeric) | 0.92 MP |
| Front camera resolution | 1280 x 720 pixels |
| Video capturing speed | 30 fps |
| Front camera HD type | HD |
| Infrared (IR) camera | Yes |
| Optical drive |
|---|
| Optical drive type | No |
| Network |
|---|
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Wi-Fi data rate (max) | 2400 Mbit/s |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Intel |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB 2.0 ports quantity | 0 |
| Combo headphone/mic port | Yes |
| USB Power Delivery (USB PD) | Yes |
| Thunderbolt 4 ports quantity | 4 |
| Intel® Thunderbolt 4 | Yes |
| Performance |
|---|
| Ambient light sensor | Yes |
| Accelerometer | Yes |
| Keyboard |
|---|
| Pointing device | Touchpad |
| Numeric keypad | No |
| Keyboard backlit | Yes |
| Keyboard language | UK English |
| Software |
|---|
| Operating system language | German, Dutch, English, French, Italian |
| Operating system architecture | 64-bit |
| Trial software | No Microsoft Office License Included 30 day Trial Offer Only |
| Operating system installed | Windows 10 Pro |
| Windows 11 free upgrade | Yes |
| Technical details |
|---|
| Market positioning | Business |
| Form factor | Clamshell |
| Product colour | Grey |
| Discrete graphics card memory | 4 GB |
| Processor special features |
|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Flex Memory Access | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
| Battery |
|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
| Battery capacity | 72 Wh |
| Battery recharge time | 4 h |
| Battery voltage | 15.4 V |
| Fast charging | Yes |
| Battery weight | 285 g |
| Power |
|---|
| AC adapter power | 130 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| USB Power Delivery (USB PD) | Yes |
| USB charging voltage | 20,5 V |
| USB charging current | 6.5 A |
| USB Type-C charging port | Yes |
| Security |
|---|
| Password protection | Yes |
| Trusted Platform Module (TPM) | Yes |
| Cable lock slot | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | -15.2 - 3048 m |
| Non-operating altitude | -15.2 - 10668 m |
| Operating shock | 110 G |
| Non-operating shock | 160 G |
| Operating vibration | 0.66 G |
| Non-operating vibration | 1.3 G |
| Weight & dimensions |
|---|
| Width | 100 mm |
| Depth | 10 mm |
| Height | 100 mm |
| Height (front) | 7.49 mm |
| Height (rear) | 1.11 cm |
| Weight | 10 g |
| Packaging data |
|---|
| Package weight | 55 g |
| Package width | 108 mm |
| Package height | 177.8 mm |
| Package depth | 25.4 mm |
| Features |
|---|
| Country of origin | Indonesia |
| Other features |
|---|
| Wi-Fi data rate (max) | 2400 Mbit/s |
| Ambient light sensor | Yes |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| On-board graphics card | Yes |
| Country of origin | Indonesia |
| Harmonized System (HS) code | 84713000 |
| Safety warning | WARNING: Not suitable for children under 36 months. Small parts. |
| Assembly required | No |
| Sensors |
|---|
| Ambient light sensor | Yes |
| Accelerometer | Yes |
| Supplier features |
|---|
| Country of origin | Indonesia |
| Logistics data |
|---|
| Harmonized System (HS) code | 84713000 |
