HPE AP‑ANT-348 network antenna SMA antenna RP-SMA 8 dBi

SKU: S1F84A | Brand: HPE

0 in stock

£354.78 ex. VAT

Figures are exclusive of VAT.

Performance
Antenna gain level (max)	8 dBi
Frequency band	2.4/5/6 GHz
Impedance	50 Ω
Antenna gain (5 GHz)	8 dBi
Antenna gain (2.4 GHz)	7.5 dBi
Features
Survival wind speed	220 km/h
Housing material	Polycarbonate (PC)
Isolation	20 dB
International Protection (IP) code	IP67
Antenna type	SMA antenna
Voltage Standing Wave Ratio (VSWR)	< 2.0:1
Product colour	Grey, White
Antenna connector type	RP-SMA
Antenna gain level (max)	8 dBi
Frequency band	2.4/5/6 GHz
Impedance	50 Ω
Antenna gain (5 GHz)	8 dBi
Antenna gain (2.4 GHz)	7.5 dBi
Operational conditions
Operating temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95%
Weight & dimensions
Weight	1 kg
Width	190 mm
Depth	40 mm
Height	190 mm
Technical details
Antenna gain level (max)	8 dBi
Frequency band	2.4/5/6 GHz
Antenna type	SMA antenna
Voltage Standing Wave Ratio (VSWR)	< 2.0:1
Impedance	50 Ω
Antenna gain (5 GHz)	8 dBi
Antenna gain (2.4 GHz)	7.5 dBi
Antenna connector type	RP-SMA
Colour
Product colour	Grey, White
