SKU: 38403  |   Brand: Lindy

Lindy 200m Fibre Optic DisplayPort 1.2 Extender

SKU: 38403  |   Brand: Lindy

Lindy 200m Fibre Optic DisplayPort 1.2 Extender

0 in stock

£189.51 ex. VAT

Figures are exclusive of VAT.



Sends DisplayPort signals up to 200m using a single fibre optic cable Transmits high-resolution DisplayPort signals up to 200m via MPO fibre optic cable Supports DisplayPort 1.2 signals with audio & DisplayPort Content Protection – DPCP Supports resolutions up to 4K 60Hz (3840 x 2160p @ 60Hz), HBR2 & MST Uncompressed 2 year warranty The LINDY Fibre Optic DisplayPort Extender sends signals over MPO fibre optic cable with no loss of quality or signal degradation from compression artifacts or electromagnetic interference. This means it is highly suited to the demanding standards required for professional signal transmission in the medical, military and presentation industries. Note: For indoor use only - in non-condensing humidity environments. You must use 12 Core 50/125µ MPO fibre optic cable with Method A termination (1:1) Package Contents: 1 x Fibre Optic DisplayPort Extender Unit 1 x Fibre Optic DisplayPort Receiver Unit 2 x Multi-Country Wall Mount Power Supplies with UK, Euro, US and AUS adapters
Performance
TypeNetwork transmitter & receiver
Maximum transfer distance200 m
Cable types supportedFiber
Technical details
LED indicatorsYes
TypeNetwork transmitter & receiver
Maximum transfer distance200 m
Cable types supportedFiber
Harmonized System (HS) code85176990
Network
Wi-FiNo
Design
Housing materialMetal
LED indicatorsYes
Product colourBlack
Power
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Input current2 A
Power consumption (typical)6 W
Operational conditions
Operating temperature (transmitter)-10 - 50 °C
Storage temperature (transmitter)-20 - 75 °C
Operating temperature (receiver)-10 - 50 °C
Storage temperature (receiver)-20 - 75 °C
Weight & dimensions
Transmitter width14 cm
Transmitter depth7.5 cm
Transmitter height3 cm
Transmitter weight250 g
Receiver width14 cm
Receiver depth7.5 cm
Receiver height3 cm
Receiver weight250 g
Weight718 g
Colour
Product colourBlack
Logistics data
Harmonized System (HS) code85176990
