SKU: 210-ALSY  |   Brand: DELL

DELL S-Series S4128F-ON Managed L2/L3 1U

SKU: 210-ALSY  |   Brand: DELL

DELL S-Series S4128F-ON Managed L2/L3 1U

0 in stock

£6,841.80 ex. VAT

Figures are exclusive of VAT.



Optimized for the open networking era
Get more agility, more choices and lower costs than proprietary networks with select, open-standards-based ON (open networking) switches. - Disaggregated-hardware/software solutions bring new levels of freedom and flexibility to your data center.
- Support for Open Network Install Environment (ONIE) enables zero-touch installation of alternate network operating systems.
- Your choice of network operating system helps simplify data-center fabric orchestration and automation.
- A broad ecosystem of open-source and Linux-based applications and tools provides more options to optimize and manage your network. Developed for flexibility
The Dell Networking S-Series 10/40GbE switches offer a family of products that enable you to find the ideal solution for your specific needs. - Line-rate performance from 1/10G BASE-T to 40GbE and port densities from 28 to 48
- Efficient stacking offered in many S-Series models
- Industry-hardened and feature-rich operating system for maximum dependability and uptime with select third-party OS options
- Full support for iSCSI storage area networks, including DCB Achieve performance, flexibility and cost-effectiveness with this ToR switch that features 28 x 10GbE SFP+ ports and 2 x 100GbE QSFP28 ports, and ONIE for zero-touch installation of alternate network operating systems.

Basic switching RJ-45 Ethernet ports quantity up to 0
Switch type Managed
Basic switching RJ-45 Ethernet ports type N
Rack mounting Y
Power over Ethernet (PoE) N
Stackable Y
Family S-Series
Weight 0.01kg

Management features
Switch typeManaged
Quality of Service (QoS) supportYes
Multicast supportYes
Switch layerL2/L3
Configuring Location Settings (CLI)Yes
Ports & interfaces
SFP+ module slots quantity28
QSFP+ module slots quantity2
Basic switching RJ-45 Ethernet ports quantity0
Basic switching RJ-45 Ethernet ports typeNo
Installed SFP modules quantity0
Network
Networking standardsIEEE 802.3
VLAN supportYes
10G supportYes
Virtual LAN featuresTagged VLAN
GARP VLAN Registration Protocol (GVRP)Yes
Multicast features
Multicast supportYes
Protocols
GARP VLAN Registration Protocol (GVRP)Yes
Design
SafetyUL/CSA 60950-L Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition Including all National Deviations and Group Differences, EN 60825-1 Safety of Laser Products Part1: Equipment Classification Requirements and User’s Guide, EN 60825-2 Safety of Laser Products Part 2: Safety of Optical Fibre Communications Systems, FDA Regulation 21 CFR 1040.10 and 1040.11
Form factor1U
StackableYes
Rack mountingYes
CertificationRoHS
Power
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Operational conditions
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)10 - 85%
Virtual LAN features
VLAN supportYes
Virtual LAN featuresTagged VLAN
Weight & dimensions
Weight8.92 kg
Performance
StackableYes
Harmonized System (HS) code85176990
Technical details
Form factor1U
StackableYes
Rack mountingYes
Certificates
SafetyUL/CSA 60950-L Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition Including all National Deviations and Group Differences, EN 60825-1 Safety of Laser Products Part1: Equipment Classification Requirements and User’s Guide, EN 60825-2 Safety of Laser Products Part 2: Safety of Optical Fibre Communications Systems, FDA Regulation 21 CFR 1040.10 and 1040.11
CertificationRoHS
Mobile network
GARP VLAN Registration Protocol (GVRP)Yes
Logistics data
Harmonized System (HS) code85176990
