| Performance |
|---|
| Video input channels | 4 channels |
| Maximum resolution | 3840 x 2160 pixels |
| Video formats supported | H.264, H.265, M-JPEG |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client) |
| Audio formats supported | AAC, G.711, G.726 |
| Throughput data rate | 50 Mbit/s |
| Syslog | Yes |
| PTZ control | Yes |
| Playback modes | Reverse, Slow play |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Recording modes | Event, Schedule |
| Maximum frame rate | 240 fps |
| Supported resolutions | 1920 x 1080, 1280 x 720 |
| Number of users | 4 user(s) |
| Number of simultaneously playbacked channels | 32 channels |
| Video recording modes | 720p, 1080p, 2160p |
| Output bandwidth | 32 Mbit/s |
| Input bandwidth | 40 Mbit/s |
| Hard drive |
|---|
| Number of HDDs supported | 1 |
| Maximum storage capacity | 6 TB |
| HDD interface | SATA |
| Storage |
|---|
| Number of HDDs supported | 1 |
| Maximum storage capacity | 6 TB |
| HDD interface | SATA |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Power over Ethernet (PoE) | Yes |
| HDMI output | Yes |
| USB 2.0 ports quantity | 2 |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client) |
| DC-in jack | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power over Ethernet (PoE) ports quantity | 4 |
| HDMI ports quantity | 1 |
| Ethernet WAN | Yes |
| Features |
|---|
| Product colour | Black |
| Power |
|---|
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 52 W |
| Total Power over Ethernet (PoE) budget | 35 W |
| System requirements |
|---|
| Windows operating systems supported | Windows 10 |
| Mac operating systems supported | Mac OS X 11.0 Big Sur |
| Browser supported | Google Chrome, Microsoft Edge, Mac Safari |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 85% |
| Weight & dimensions |
|---|
| Width | 300 mm |
| Depth | 208.4 mm |
| Height | 47.6 mm |
| Weight | 1.03 kg |
