| Performance |
|---|
| Video input channels | 8 channels |
| Alarm input channels | 4 |
| Alarm output channels | 1 |
| Maximum resolution | 3840 x 2160 pixels |
| Video codecs | H.265+/H.265/H.264+/H.264/MPEG4 |
| Supported network protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Audio codecs | G.711ulaw/G.711alaw/G.722/G.726/MP2L2 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Supported resolutions | (3840 × 2160, 2560 × 1440, 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768 |
| Face detection | Yes |
| Number of simultaneously playbacked channels | 8 channels |
| Output bandwidth | 256 Mbit/s |
| Input bandwidth | 80 Mbit/s |
| Wireless LAN features |
|---|
| Wi-Fi | No |
| Hard drive |
|---|
| Number of HDDs supported | 2 |
| Maximum storage capacity | 20 TB |
| HDD interface | SATA, SATA II, SATA III |
| Number of HDDs installed | 0 |
| HDD capacity | 0 GB |
| Storage |
|---|
| Number of HDDs supported | 2 |
| Maximum storage capacity | 20 TB |
| HDD interface | SATA, SATA II, SATA III |
| Number of HDDs installed | 0 |
| HDD capacity | 0 GB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 9 |
| Power over Ethernet (PoE) | Yes |
| VGA (D-Sub) output ports | 1 |
| USB 2.0 ports quantity | 1 |
| Supported network protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Audio RCA inputs | 1 |
| DC-in jack | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Audio RCA outputs | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Power over Ethernet (PoE) ports quantity | 8 |
| HDMI ports quantity | 1 |
| Features |
|---|
| Rack mounting | Yes |
| Certification | FCC 15 B, ANSI C63.4-2014 CE 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4 |
| Rack capacity | 1U |
| Product colour | Black |
| Power |
|---|
| Power consumption (typical) | 30 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| Operational conditions |
|---|
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions |
|---|
| Width | 385 mm |
| Depth | 315 mm |
| Height | 52 mm |
| Weight | 2.5 kg |
