SKU: EPDU1232SX3620  |   Brand: APC

APC EPDU1232SX3620 power distribution unit (PDU) 36 AC outlet(s) 0U Black

SKU: EPDU1232SX3620  |   Brand: APC

APC EPDU1232SX3620 power distribution unit (PDU) 36 AC outlet(s) 0U Black

9 in stock

£1,530.47 ex. VAT

Figures are exclusive of VAT.



Easy Switched Rack Power Distribution Units (Rack PDU) provide on/off outlet switching, advanced power management, load monitoring and much more features than the average power strip.

Weight 9,560.00kg

Design
PDU typesSwitched
MountingVertical
Product colourBlack
CertificationEAC, RCM, TÜV
Rack capacity0U
Ports & interfaces
AC outlets quantity36 AC outlet(s)
AC outlet typesC13 coupler, C19 coupler
Power plugIEC 320
Features
Cable length2 m
CertificationEAC, RCM, TÜV
Ergonomics
Cable length2 m
Power
Maximum power22000 W
Nominal input voltage400 V
Output voltage230 V
Maximum current32 A
AC input frequency60 / 50 Hz
Certificates
CertificationEAC, RCM, TÜV
Compliance certificatesCE
Sustainability
Sustainability complianceYes
Operational conditions
Operating temperature (T-T)-5 - 45 °C
Storage temperature (T-T)-25 - 65 °C
Storage relative humidity (H-H)5 - 95%
Operating relative humidity (H-H)5 - 95%
Operating altitude0 - 3000 m
Weight & dimensions
Weight8.28 kg
Width55 mm
Depth62 mm
Height1794 mm
Package width160 mm
Package depth110 mm
Package height1950 mm
Package weight9.56 kg
Packaging data
Package width160 mm
Package depth110 mm
Package height1950 mm
Package weight9.56 kg
Technical details
Sustainability complianceYes
Compliance certificatesCE
