| Performance |
|---|
| Number of languages | 11 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Certification | EN/IEC 55032 Class A, EN/IEC 61000-3-2,EN/IEC 61000-3-3, EN/IEC 61000-6-1, EN/IEC 61000-6-2, EN/IEC 55035, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), RCM AS/NZS CISPR 32 Class A |
| Design |
|---|
| Product colour | Stainless steel |
| Mounting type | Ceiling/wall |
| Housing material | Stainless steel |
| Camera |
|---|
| Minimum illumination | 0.16 lx |
| Tilt angle range | -90 - 90° |
| Tilt speed | 200 °/sec |
| Pan range | 0 - 360° |
| Pan speed | 200 °/sec |
| Angle of rotation | 180° |
| Camera shutter speed | 1/66500 - 1 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Auto focus | Yes |
| Zoom capability | Yes |
| Optical zoom | 32x |
| Digital zoom | 12x |
| Focal length range | 4.3 - 137 mm |
| Night vision |
|---|
| Night vision | Yes |
| Video |
|---|
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Image stabilizer | Yes |
| Bit rate control | Variable Bit Rate (VBR) |
| Video compression formats | H.264 |
| Maximum resolution | 1920 x 1080 pixels |
| Frame rate | 60 fps |
| Video streaming | Yes |
| Video recording | Yes |
| Network |
|---|
| Quality of Service (QoS) support | Yes |
| Ethernet LAN | No |
| Wi-Fi | No |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6,, DDNS, NTP, RTSP, RTCP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf) |
| Storage |
|---|
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSDXC |
| Internal memory | 1024 MB |
| Flash memory | 512 MB |
| Ports & interfaces |
|---|
| Connectivity technology | Wired |
| Security |
|---|
| Alert notification type | E-mail |
| Video motion detection | Yes |
| Security algorithms | 802.1x RADIUS |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Active tampering alarm | Yes |
| Password protection | Yes |
| Pixel counter | Yes |
| Digest authentication | Yes |
| Power |
|---|
| Power source type | AC |
| AC input voltage | 100 - 240 V |
| Certificates |
|---|
| Certification | EN/IEC 55032 Class A, EN/IEC 61000-3-2,EN/IEC 61000-3-3, EN/IEC 61000-6-1, EN/IEC 61000-6-2, EN/IEC 55035, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), RCM AS/NZS CISPR 32 Class A |
| Operational conditions |
|---|
| Operating temperature (T-T) | -60 - 60 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage relative humidity (H-H) | 0 - 98% |
| Weight & dimensions |
|---|
| Width | 190 mm |
| Depth | 234 mm |
| Height | 250 mm |
| Weight | 23 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Mounting kit | Yes |
| Other features |
|---|
| Video compression formats | H.264 |
