Performance |
---|
Infrared (IR) cut-off filter | Yes |
Languages support | Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
PTZ modes | Digital PTZ |
Type | IP security camera |
Connectivity technology | Wired |
PTZ control | Yes |
Placement supported | Indoor & outdoor |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Design |
---|
IK code | IK10 |
Form factor | Dome |
Product colour | White |
Mounting type | Ceiling |
International Protection (IP) code | IP66 |
Camera |
---|
Minimum illumination | 0.1 lx |
Field of view (FOV) angle | 100° |
Tilt angle range | 0 - 75° |
Pan range | -180 - 180° |
Camera shutter type | Electronic |
Camera shutter speed | 1/66500 - 2 s |
Image sensor |
---|
Sensor type | CMOS |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Number of sensors | 1 |
Lens system |
---|
Number of lenses | 1 |
Zoom capability | Yes |
Focal length range | 8.9 mm |
Night vision |
---|
Night vision | Yes |
Video |
---|
Noise reduction | Yes |
Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
Flip & mirror | Yes |
Image stabilizer | No |
Noise reduction technology | 2D noise reduction, 3D noise reduction |
Video compression formats | H.264, H.265 |
Maximum resolution | 1920 x 1080 pixels |
Video formats supported | M-JPEG |
Supported graphics resolutions | 160 x 120, 160 x 90, 1440 x 1080, 1440 x 900 (WXGA+), 1920 x 1080 (HD 1080) |
Frame rate | 60 fps |
Video streaming | Yes |
Audio |
---|
Built-in speaker(s) | Yes |
Signal-to-Noise Ratio (SNR) | 55 dB |
Built-in microphone | No |
Audio formats supported | AAC-LC, G.711, G.726, LPCM, OPUS |
Network |
---|
Bluetooth | No |
Ethernet LAN | Yes |
Wi-Fi | No |
Supported network protocols | Pv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS2 , HTTP/ 2, TLS2 , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
Storage |
---|
Built-in HDD | Yes |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
Flash memory | 8192 MB |
RAM capacity | 1024 MB |
Ports & interfaces |
---|
Ethernet LAN (RJ-45) ports | 1 |
Connectivity technology | Wired |
Security |
---|
Detection distance | 7 m |
Operational conditions |
---|
Operating temperature (T-T) | -40 - 50 °C |
Storage temperature (T-T) | -40 - 65 °C |
Operating relative humidity (H-H) | 10 - 100% |
Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions |
---|
Height | 104 mm |
Diameter | 14.9 cm |
Weight | 800 g |
Packaging content |
---|
Number of cameras | 1 |
Screws included | Yes |
Packaging content | Camera, weathershield, installation guide, drill template, RESISTORX® TR20 screw bit, terminal block connector, connector guard, cable gaskets, Windows® decoder 1–user license, owner authentication key |
Technical details |
---|
Doesn't contain | PVC |
Other features |
---|
Video compression formats | H.264, H.265 |
Doesn't contain | PVC |
