| Performance |
|---|
| Languages support | Czech, German, Dutch, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Turkish |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Dynamic range | 120 dB |
| Design |
|---|
| IK code | IK10 |
| Form factor | Bullet |
| Product colour | White |
| Mounting type | Ceiling/wall |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Aluminium |
| Camera |
|---|
| Minimum illumination | 0 lx |
| White balance | ATW, AWC, Indoor, Manual, Outdoor |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/5~1/12,000 s |
| Lens viewing angle, horizontal | 60.92 - 2.2° |
| Lens viewing angle, vertical | 35.26 - 1.24° |
| Lens viewing angle, diagonal | 69.18 - 2.52° |
| Image sensor |
|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Lens system |
|---|
| Maximum aperture number | 4.6 |
| Recognize distance (wide) | 26.1 m |
| Recognize distance (tele) | 800 m |
| Observe distance (wide) | 52.2 m |
| Observe distance (tele) | 1600 m |
| Identify distance (wide) | 13.1 m |
| Identify distance (tele) | 400 m |
| Detect distance (wide) | 130.6 m |
| Detect distance (tele) | 4000 m |
| Closest focusing distance | 3 m |
| Focal length range | 6.91 - 214.7 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 70 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Noise reduction | Yes |
| Privacy masking | Yes |
| Image stabilizer | Yes |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | WiseNR Ⅱ |
| Video compression formats | H.264, H.265, M-JPEG |
| Maximum resolution | 3840 x 2160 pixels |
| Supported graphics resolutions | 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2560 x 1440, 2592 x 1944, 2688 x 1520, 3072 x 1728, 3840 x 2160 |
| Frame rate | 30 fps |
| Audio |
|---|
| Voice codecs | G.711ulaw, G.726 |
| Audio detection | Yes |
| Network |
|---|
| Ethernet interface type | Gigabit Ethernet |
| Streaming method | Multicast, Unicast |
| Ethernet LAN | Yes |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast), MQTT |
| Storage |
|---|
| Maximum memory card size | 512 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), SDHC, SDXC |
| Flash memory | 1024 MB |
| RAM capacity | 4096 MB |
| Ports & interfaces |
|---|
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Alert notification type | E-mail |
| Intelligent Video Surveillance (IVS) system features | Crossing line, Defocus, Face detection, Human detection, Vehicle detection |
| Video motion detection | Yes |
| Security algorithms | EAP-LEAP, EAP-TLS, FIPS 140-2 |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (Power over Ethernet (PoE)) | 25.5 W |
| DC output voltage | 12 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 55 °C |
| Storage temperature (T-T) | -50 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 90% |
| Weight & dimensions |
|---|
| Length | 358.7 mm |
| Diameter | 13.6 cm |
| Weight | 3.2 kg |
| Sustainability |
|---|
| Compliance certificates | National Defense Authorization Act (NDAA), Trade Agreements Act (TAA) |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Compliance certificates | National Defense Authorization Act (NDAA), Trade Agreements Act (TAA) |
| Other features |
|---|
| Video compression formats | H.264, H.265, M-JPEG |
