| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Remote viewing | Yes |
| Fog proof | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Auto-tracking | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Certification | EN55011:2009+A1:2010, EN50581:2012,EN50121-3-2:2015, EN61000-4-2:2009, EN61000-4-3:2006+A2:2010, EN61000-4-4:2012, EN61000-4-5:2014 EN61000-4-6:2009, EN50155:2007 |
| Design |
|---|
| IK code | IK10 |
| Fog proof | Yes |
| Product colour | Ivory |
| Protection features | Vandal proof |
| International Protection (IP) code | IP66 |
| Housing material | Metal |
| Camera |
|---|
| Minimum illumination | 0.004 lx |
| Tilt angle range | 0 - 67° |
| Pan range | -5 - 5° |
| White balance | ATW, AWC, Indoor, Manual, Outdoor |
| Angle of rotation | 180° |
| Camera shutter type | Electronic |
| Camera shutter speed | 2 - 1/12000 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 135.4° |
| Lens viewing angle, vertical | 71.2° |
| Lens viewing angle, diagonal | 161.6° |
| Image sensor |
|---|
| Number of effective pixels (H x V) | 1945 x 1079 pixels |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 2 |
| Focus | Manual |
| Fixed focal length | 2.4 mm |
| Night vision |
|---|
| Night vision | No |
| Video |
|---|
| Noise reduction | Yes |
| Privacy masking | Yes |
| Flip & mirror | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Maximum resolution | 1920 x 1080 pixels |
| Video formats supported | H.264, H.265, M-JPEG |
| Supported graphics resolutions | 320 x 240, 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960 |
| Frame rate | 60 fps |
| Total megapixels | 2 MP |
| Audio |
|---|
| Sample rate | 16 kHz |
| Built-in microphone | Yes |
| Audio formats supported | ADPCM, G.711, G.726, LC-AAC |
| Audio detection | Yes |
| Network |
|---|
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3af |
| Quality of Service (QoS) support | Yes |
| Number of users | 20 user(s) |
| Streaming method | Multicast, Unicast |
| Ethernet LAN | Yes |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP |
| Storage |
|---|
| Maximum memory card size | 256 GB |
| Card reader integrated | Yes |
| Compatible memory cards | SD, SDHC, SDXC |
| Internal memory | 1024 MB |
| Flash memory | 256 MB |
| Ports & interfaces |
|---|
| USB port | Yes |
| Microphone in | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Alert notification type | E-mail |
| Intelligent Video Surveillance (IVS) system features | Crossing line, Defocus, Face detection |
| Video motion detection | Yes |
| Security algorithms | 802.1x RADIUS, EAP-TLS |
| IP address filtering | Yes |
| Anti-flicker | Yes |
| Power |
|---|
| Power source type | PoE |
| Power consumption (Power over Ethernet (PoE)) | 6.5 W |
| Certificates |
|---|
| Certification | EN55011:2009+A1:2010, EN50581:2012,EN50121-3-2:2015, EN61000-4-2:2009, EN61000-4-3:2006+A2:2010, EN61000-4-4:2012, EN61000-4-5:2014 EN61000-4-6:2009, EN50155:2007 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 55 °C |
| Storage temperature (T-T) | -50 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 90% |
| System requirements |
|---|
| Windows operating systems supported | Windows 10, Windows 7, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
| Weight & dimensions |
|---|
| Width | 98.9 mm |
| Depth | 100 mm |
| Height | 52 mm |
| Weight | 295 g |
| Packaging content |
|---|
| Number of cameras | 1 |
| Other features |
|---|
| Focus | Manual |
