| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 33 |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Design |
|---|
| Form factor | Cube |
| Product colour | Black, White |
| Mounting type | Ceiling/wall |
| Housing material | Plastic |
| Camera |
|---|
| Minimum illumination | 0 lx |
| Tilt angle range | 0 - 90° |
| Pan range | 0 - 360° |
| Angle of rotation | 360° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 107.8° |
| Lens viewing angle, vertical | 57.9° |
| Lens viewing angle, diagonal | 126.7° |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 2 |
| Detect distance | 85.5 m |
| Observe distance | 33.9 m |
| Recognize distance | 17.1 m |
| Identify distance | 8.6 m |
| Fixed focal length | 2.8 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 10 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Mirror, Saturation, Sharpness |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | 32 Kbps - 16 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
| Maximum resolution | 3840 x 2160 pixels |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 8 MP |
| Audio |
|---|
| Voice codecs | G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2 |
| Built-in speaker(s) | Yes |
| Sample rate | 48 kHz |
| Built-in microphone | Yes |
| Audio formats supported | MP3 |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3af |
| Quality of Service (QoS) support | Yes |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, QoS, 802.1X, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP |
| Storage |
|---|
| Maximum memory card size | 256 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Motion sensor | Yes |
| Motion sensor technology | Passive infrared (PIR) sensor |
| Detection distance | 8 m |
| Video motion detection | Yes |
| Mirror | Yes |
| Management features |
|---|
| Web-based management | Yes |
| Reset button | Yes |
| Behavior analysis | Intrusion detection, Line crossing detection |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 5.9 W |
| Power consumption (Power over Ethernet (PoE)) | 6.9 W |
| DC output voltage | 12 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -10 - 40 °C |
| Storage temperature (T-T) | -10 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Width | 102.9 mm |
| Depth | 65.2 mm |
| Height | 32.6 mm |
| Weight | 120 g |
| Package width | 150 mm |
| Package height | 99 mm |
| Package depth | 125 mm |
| Package weight | 430 g |
| Packaging data |
|---|
| Package width | 150 mm |
| Package height | 99 mm |
| Package depth | 125 mm |
| Package weight | 430 g |
| Packaging content |
|---|
| Number of cameras | 1 |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
