| Performance |
|---|
| Number of languages | 33 |
| Languages support | English, Polish, Thai, Spanish, Italian, Portuguese, Turkish, Bulgarian, Japanese, Romanian, Ukrainian, Finnish, Russian, Vietnamese, French, Korean, Traditional Chinese, Greek, LAT, SER, Czech, Slovak, Danish, Lithuanian, Slovenian, German, HRV, Dutch, Hungarian, Norwegian, Swedish |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Built-in light | Yes |
| Colour temperature | 3000 K |
| Dynamic range | 130 dB |
| Design |
|---|
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling |
| Protection features | Dust resistant, Water resistant |
| International Protection (IP) code | IP67 |
| Camera |
|---|
| Minimum illumination | 0.0005 lx |
| Tilt angle range | 0 - 75° |
| Pan range | 0 - 360° |
| Angle of rotation | 360° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Lens viewing angle, horizontal | 112° |
| Lens viewing angle, vertical | 61° |
| Lens viewing angle, diagonal | 134° |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1 |
| Detect distance | 58 m |
| Observe distance | 23 m |
| Recognize distance | 11 m |
| Identify distance | 2 m |
| Fixed focus | Yes |
| Fixed focal length | 2.8 mm |
| Night vision |
|---|
| Night vision | Yes |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Sharpness |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate | 32 Kbps - 8 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
| Maximum resolution | 2688 x 1520 pixels |
| Supported graphics resolutions | 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520 |
| Total megapixels | 4 MP |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Built-in microphone | Yes |
| Audio formats supported | AAC, G.711 A-law, G.711 μ-law, G.722.1, G.726, MP2L2, MP3, PCM |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 8 - 320 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 6 channels |
| Live view | Yes |
| Storage |
|---|
| Maximum memory card size | 256 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Mirror | Yes |
| Heartbeat | Yes |
| Anti-flicker | Yes |
| Pixel counter | Yes |
| Password reset via email | Yes |
| Flash log | Yes |
| Management features |
|---|
| Software reset | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 6.6 W |
| Power consumption (Power over Ethernet (PoE)) | 7.6 W |
| DC output voltage | 12 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Height | 125.2 mm |
| Diameter | 13.8 cm |
| Weight | 790 g |
| Package width | 170 mm |
| Package height | 150 mm |
| Package depth | 170 mm |
| Package weight | 1.07 kg |
| Packaging data |
|---|
| Package width | 170 mm |
| Package height | 150 mm |
| Package depth | 170 mm |
| Package weight | 1.07 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Lens mount interface | M16 |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
