Performance |
---|
Number of languages | 33 |
Languages support | Multi |
Type | IP security camera |
Connectivity technology | Wired |
Placement supported | Indoor & outdoor |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Alarm input/output | Yes |
Dynamic range | 120 dB |
Design |
---|
Form factor | Turret |
Product colour | White |
Mounting type | Ceiling/wall |
International Protection (IP) code | IP67 |
Housing material | Metal |
Camera |
---|
Minimum illumination | 0.0005 lx |
Tilt angle range | 0 - 75° |
Pan range | 0 - 360° |
Angle of rotation | 360° |
Camera shutter speed | 1/3 - 1/100000 s |
Camera pan control | Yes |
Camera tilt control | Yes |
Lens viewing angle, horizontal | 102° |
Lens viewing angle, vertical | 52° |
Lens viewing angle, diagonal | 124° |
Progressive scan | Yes |
Image sensor |
---|
Sensor type | CMOS |
Progressive scan | Yes |
Optical sensor size | 25.4 / 1.2 mm (1 / 1.2") |
Lens system |
---|
Number of lenses | 1 |
Detect distance | 96 m |
Observe distance | 38 m |
Recognize distance | 19 m |
Identify distance | 9 m |
Fixed focal length | 2.8 mm |
Video |
---|
Image quality adjustment | Brightness, Contrast, Mirror, Sharpness, DNR, Saturation |
Privacy masking | Yes |
Region of Interest (ROI) encoding | Yes |
Highlight Compensation (HLC) | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Bit rate | 32 Kbps to 16 Mbps |
Back Light Compensation (BLC) | Yes |
Video compression formats | H.265+, H.264, H.264+, H.265 |
Maximum resolution | 3840 x 2160 pixels |
Supported graphics resolutions | 1280 x 720 (HD 720), 3200 x 1800, 3840 x 2160, 2688 x 1520, 640 x 480 (VGA), 1920 x 1080 (HD 1080), 640 x 360 |
Frame rate | 30 fps |
Total megapixels | 8 MP |
Audio |
---|
Voice codecs | PCM, G.722.1, G.711alaw, G.726, G.711ulaw, MP2L2 |
Signal-to-Noise Ratio (SNR) | 52 dB |
Built-in microphone | Yes |
Audio formats supported | MP3, AAC |
Sample rates | 8 - 48 kHz |
Bit rate range | 16 - 64 Kbit/s |
Network |
---|
Bluetooth | No |
Ethernet interface type | Fast Ethernet |
Number of users | 32 user(s) |
Ethernet LAN | Yes |
Wi-Fi | No |
Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, ARP, SNMP |
User access level | Administrator, Operator, User |
Number of simultaneous live view channels | 6 channels |
Storage |
---|
Maximum memory card size | 256 GB |
Card reader integrated | Yes |
Built-in HDD | No |
Compatible memory cards | MicroSD (TransFlash), SDHC, SDXC |
Ports & interfaces |
---|
Ethernet LAN (RJ-45) ports | 1 |
Connectivity technology | Wired |
Security |
---|
Video motion detection | Yes |
IP address filtering | Yes |
HTTPS encryption | Yes |
Active tampering alarm | Yes |
Password protection | Yes |
Mirror | Yes |
Heartbeat | Yes |
Anti-flicker | Yes |
Pixel counter | Yes |
Password reset via email | Yes |
Flash log | Yes |
Digest authentication | Yes |
Automatic Network Replenishment (ANR) | Yes |
Audit log | Yes |
Alarm input channels | 1 |
Alarm output channels | 1 |
Management features |
---|
Web browser | Yes |
Behavior analysis | Intrusion detection, Region exiting detection, Line crossing detection, Region entrance detection |
Software reset | Yes |
Power |
---|
Power source type | DC, PoE |
Power consumption (max) | 5.6 W |
Power consumption (Power over Ethernet (PoE)) | 6.6 W |
Power consumption | 470 mA |
DC output voltage | 12 |
DC output current | 0.1 A |
Operational conditions |
---|
Operating temperature (T-T) | -30 - 60 °C |
Storage temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Weight & dimensions |
---|
Height | 120.1 mm |
Diameter | 13.8 cm |
Weight | 910 g |
Package width | 170 mm |
Package height | 150 mm |
Package depth | 170 mm |
Package weight | 1.19 kg |
Packaging data |
---|
Package width | 170 mm |
Package height | 150 mm |
Package depth | 170 mm |
Package weight | 1.19 kg |
Sustainability |
---|
Compliance certificates | CB, CE, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), Industry Canada (IC), KC, Low Voltage Directive (LVD), RCM, REACH, RoHS, UL, WEEE |
Packaging content |
---|
Number of cameras | 1 |
Technical details |
---|
Compliance certificates | CB, CE, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), Industry Canada (IC), KC, Low Voltage Directive (LVD), RCM, REACH, RoHS, UL, WEEE |
Other features |
---|
Video compression formats | H.265+, H.264, H.264+, H.265 |
