| Performance |
|---|
| Number of languages | 18 |
| Languages support | Multi |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Certification | CE-RoHS, WEEE, Reach |
| Cable length | 2 m |
| Dynamic range | 120 dB |
| Design |
|---|
| Form factor | Covert |
| Product colour | Black |
| Camera |
|---|
| Camera shutter speed | 1/3 - 1/100000 s |
| Lens viewing angle, horizontal | 75.5° |
| Lens viewing angle, vertical | 41.6° |
| Lens viewing angle, diagonal | 87.3° |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 2.5 |
| Detect distance | 59.3 m |
| Observe distance | 23.5 m |
| Recognize distance | 11.9 m |
| Identify distance | 5.9 m |
| Fixed focal length | 3.7 mm |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264+, H.265, H.265+, M-JPEG |
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 320 x 240, 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 2 MP |
| Audio |
|---|
| Voice codecs | AAC, G.711, G.722.1, G.726, MP2L2, PCM |
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Sample rates | 8 - 32 kHz |
| Bit rate range | 16 - 192 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Client interoperability | iVMS-4200, Hik-Connect |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 15 channels |
| Live view | Yes |
| Storage |
|---|
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces |
|---|
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Privacy protection | Yes |
| Video motion detection | Yes |
| IP address filtering | Yes |
| Active tampering alarm | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Heartbeat | Yes |
| Digital watermark | Yes |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Management features |
|---|
| Web-based management | Yes |
| Reset button | Yes |
| Behavior analysis | Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection, Unattended baggage detection |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 3 W |
| Power consumption (Power over Ethernet (PoE)) | 3.65 W |
| DC output voltage | 12 |
| DC output current | 0.25 A |
| Certificates |
|---|
| Certification | CE-RoHS, WEEE, Reach |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Length | 25 mm |
| Diameter | 2.6 cm |
| Weight | 90 g |
| Package width | 219 mm |
| Package height | 100 mm |
| Package depth | 139 mm |
| Package weight | 451 g |
| Cable length | 2 m |
| Packaging data |
|---|
| Package width | 219 mm |
| Package height | 100 mm |
| Package depth | 139 mm |
| Package weight | 451 g |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Iris | Yes |
| Other features |
|---|
| Video compression formats | H.264+, H.265, H.265+, M-JPEG |
