| Performance |
|---|
| Number of languages | 32 |
| Languages support | English, Norwegian, Spanish, Swedish, Estonian, Italian, Polish, Thai, Finnish, Japanese, Portuguese, Turkish, French, Romanian, Traditional Chinese, Greek, Korean, Russian, Vietnamese, Czech, LAT, Danish, SER, German, Lithuanian, Slovak, Dutch, Hungarian, Slovenian |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Built-in light | Yes |
| Dynamic range | 120 dB |
| Design |
|---|
| Form factor | Dome |
| Product colour | Black, White |
| Mounting type | Ceiling |
| International Protection (IP) code | IP66 |
| Camera |
|---|
| Tilt preset speed | 50 °/sec |
| Pan preset speed | 60 °/sec |
| Minimum illumination | 0.0005 lx |
| Tilt angle range | 0 - 90° |
| Tilt speed | 50 °/sec |
| Pan range | 0 - 350° |
| Pan speed | 60 °/sec |
| Camera shutter speed | 1/1 - 1/30000 s |
| Lens viewing angle, horizontal | 88.7° |
| Lens viewing angle, vertical | 46.5° |
| Lens viewing angle, diagonal | 105° |
| Image sensor |
|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Maximum aperture number | 1 |
| Digital zoom | 16x |
| Focal length range | 4 mm |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
| Maximum resolution | 2560 x 1440 pixels |
| Supported graphics resolutions | 352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2560 x 1440 |
| Total megapixels | 4 MP |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Audio formats supported | AAC, G.711 A-law, G.711 μ-law, G.722.1, G.726, MP2L2, PCM |
| Network |
|---|
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 20 channels |
| Live view | Yes |
| Storage |
|---|
| Maximum memory card size | 512 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces |
|---|
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Intelligent Video Surveillance (IVS) system features | Face detection |
| Video motion detection | Yes |
| Security algorithms | HTTPS |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Active tampering alarm | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Digital watermark | Yes |
| Management features |
|---|
| Web browser | Yes |
| Reset button | Yes |
| Behavior analysis | Line crossing detection, Region entrance detection, Region exiting detection |
| Power |
|---|
| Power source type | PoC, PoE |
| Power consumption (max) | 16 W |
| Power consumption | 60 mA |
| DC output voltage | 12 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 65 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions |
|---|
| Width | 120 mm |
| Depth | 179.3 mm |
| Height | 182 mm |
| Diameter | 12 cm |
| Weight | 1.12 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
