| Performance |
|---|
| Preset points | Yes |
| PTZ modes | 4 Pattern |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Dynamic range | 120 dB |
| Design |
|---|
| Form factor | Dome |
| Product colour | Black, White |
| Mounting type | Ceiling |
| International Protection (IP) code | IP67 |
| Camera |
|---|
| Tilt preset speed | 80 °/sec |
| Pan preset speed | 80 °/sec |
| Preset programs quantity | 300 |
| Minimum illumination | 0 lx |
| Tilt angle range | 0 - 360° |
| Tilt speed | 80 °/sec |
| Pan range | -15 - 90° |
| Pan speed | 80 °/sec |
| White balance | ATW, Auto, Fluorescent, Indoor, MWB, Outdoor, Sodium lamp |
| Camera shutter speed | 1 - 1/30000 s |
| Lens viewing angle, horizontal | 96.1° |
| Lens viewing angle, vertical | 52.1° |
| Lens viewing angle, diagonal | 113.3° |
| Image sensor |
|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Lens system |
|---|
| Number of lenses | 2 |
| Maximum aperture number | 1.6 |
| Auto focus | Yes |
| Detect distance | 1320 m |
| Observe distance | 523.8 m |
| Recognize distance | 264 m |
| Identify distance | 132 m |
| Minimum aperture number | 1 |
| Focus | Motorized/Manual |
| Zoom capability | Yes |
| Optical zoom | 15x |
| Digital zoom | 16x |
| Focal length range | 4.8 - 72 mm |
| Fixed focal length | 2.8 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 100 m |
| LED type | IR |
| B/W night vision distance | 30 m |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Image stabilizer | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | 32 Kbps - 16 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.265, M-JPEG |
| Maximum resolution | 2560 x 1440 pixels |
| Supported graphics resolutions | 352 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2560 x 1440 |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 4 MP |
| Audio |
|---|
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Audio formats supported | AAC-LC, G.711, G.722.1, G.726, MP2L2, PCM |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 16 - 160 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| Quality of Service (QoS) support | Yes |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,R TP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,WebSocket,WebSockets |
| Client interoperability | iVMS-4200, Hik-Connect |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 20 channels |
| Live view | Yes |
| Storage |
|---|
| Maximum memory card size | 256 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDXC |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Video motion detection | Yes |
| Security algorithms | 802.1x RADIUS, HTTPS |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Digital watermark | Yes |
| Automatic Network Replenishment (ANR) | Yes |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Management features |
|---|
| Web-based management | Yes |
| Software reset | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 24 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 65 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions |
|---|
| Height | 375 mm |
| Diameter | 16.6 cm |
| Weight | 2.4 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Output connections | Audio Output x1 |
| Audio input | 1 |
| Other features |
|---|
| Focus | Motorized/Manual |
| Video compression formats | H.264, H.265, M-JPEG |
| Browser supported | IE 10+, Chrome 57+, Firefox 52+, Safari 12+ |
