| Performance |
|---|
| Number of languages | 33 |
| Languages support | Multi |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Built-in light | Yes |
| Dynamic range | 120 dB |
| Design |
|---|
| Form factor | Bulb |
| Product colour | White |
| Mounting type | Pole clamp |
| International Protection (IP) code | IP65 |
| Housing material | Metal, Plastic |
| Camera |
|---|
| Minimum illumination | 0 lx |
| Tilt angle range | -5 - 105° |
| Pan range | 0 - 340° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Lens viewing angle, horizontal | 75° |
| Lens viewing angle, vertical | 40° |
| Lens viewing angle, diagonal | 89° |
| Number of Privacy masking areas | 4 |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1 |
| Detect distance | 82 m |
| Observe distance | 32 m |
| Recognize distance | 16 m |
| Identify distance | 8 m |
| Closest focusing distance | 2.7 m |
| Fixed focal length | 4 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | White |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | 32 Kbps - 8 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
| Maximum resolution | 2688 x 1520 pixels |
| Supported graphics resolutions | 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520 |
| Total megapixels | 4 MP |
| Audio |
|---|
| Voice codecs | G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM |
| Built-in speaker(s) | Yes |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Built-in microphone | Yes |
| Audio formats supported | AAC-LC, MP3 |
| Sample rates | 8 - 16 kHz |
| Bit rate range | 8 - 320 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| 4G standard | LTE-TDD & LTE-FDD |
| Ethernet interface type | Fast Ethernet |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, ICMP, HTTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP |
| SIM card slot | Yes |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 6 channels |
| Live view | Yes |
| SIM card type | MicroSIM |
| Mobile network generation | 4G |
| Storage |
|---|
| Maximum memory card size | 256 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 64 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Privacy protection | Yes |
| Video motion detection | Yes |
| Security algorithms | TLS |
| HTTPS encryption | Yes |
| Active tampering alarm | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Heartbeat | Yes |
| Flash log | Yes |
| Automatic Network Replenishment (ANR) | Yes |
| Management features |
|---|
| Web-based management | Yes |
| Reset button | Yes |
| Power |
|---|
| Power source type | DC |
| Power consumption (max) | 6 W |
| Battery voltage | 12.6 V |
| Battery technology | Lithium |
| Battery capacity | 8400 mAh |
| DC output voltage | 12 |
| Battery |
|---|
| Battery voltage | 12.6 V |
| Battery technology | Lithium |
| Battery capacity | 8400 mAh |
| Battery weight | 1.4 kg |
| Operational conditions |
|---|
| Operating temperature (T-T) | -20 - 50 °C |
| Storage temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Width | 686.6 mm |
| Depth | 442.6 mm |
| Height | 760 mm |
| Weight | 11.7 kg |
| Package width | 902 mm |
| Package height | 440 mm |
| Package depth | 342 mm |
| Package weight | 15 kg |
| Packaging data |
|---|
| Package width | 902 mm |
| Package height | 440 mm |
| Package depth | 342 mm |
| Package weight | 15 kg |
| Sustainability |
|---|
| Sustainability compliance | Yes |
| Compliance certificates | CB, CE, Low Voltage Directive (LVD), RoHS, WEEE |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Sustainability compliance | Yes |
| Compliance certificates | CB, CE, Low Voltage Directive (LVD), RoHS, WEEE |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
