| Performance |
|---|
| Number of languages | 33 |
| Languages support | English, Norwegian, Spanish, Swedish, Bulgarian, Estonian, Italian, Thai, Finnish, Japanese, Portuguese, Romanian, Ukrainian, Traditional Chinese, Greek, Russian, Vietnamese, LAT, Danish, SER, German, HRV, Lithuanian, Dutch, Hungarian, Slovenian |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Built-in light | Yes |
| Dynamic range | 130 dB |
| Design |
|---|
| Form factor | Bullet |
| Product colour | Grey, White |
| Mounting type | Pole clamp |
| Protection features | Wind resistant |
| International Protection (IP) code | IP67 |
| Housing material | Metal |
| Camera |
|---|
| Minimum illumination | 0.0005 lx |
| Lens viewing angle, horizontal | 101.6° |
| Lens viewing angle, vertical | 52.4° |
| Lens viewing angle, diagonal | 124° |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.2 mm (1 / 1.2") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Detect distance | 96 m |
| Observe distance | 38 m |
| Recognize distance | 19 m |
| Identify distance | 9.5 m |
| Minimum aperture number | 1 |
| Fixed focal length | 4 mm |
| Night vision |
|---|
| Night vision | No |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Maximum resolution | 3840 x 2160 pixels |
| Video formats supported | H.264, H.265, M-JPEG |
| Supported graphics resolutions | 3860 x 2160, 480 x 360, 2688 x 1520, 640 x 480 (VGA), 1920 x 1080 (HD 1080), 1920 x 720 |
| Total megapixels | 8 MP |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Audio formats supported | G.722.1, MP2L2, MP3, G.726, AAC-LC, PCM, G.711 |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 16 - 192 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| 4G standard | LTE-TDD & LTE-FDD |
| Ethernet interface type | Fast Ethernet |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets |
| SIM card slot | Yes |
| 2G standards | GSM |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 6 channels |
| Live view | Yes |
| SIM card type | MicroSIM |
| 3G standards | WCDMA |
| Mobile network generation | 4G |
| Mobile network connection | Yes |
| Storage |
|---|
| Maximum memory card size | 256 GB |
| Card reader integrated | Yes |
| Built-in HDD | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| SSD capacity | 64 GB |
| Ports & interfaces |
|---|
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Security algorithms | EAP-LEAP, EAP-MD5, EAP-TLS, HTTPS |
| IP address filtering | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Heartbeat | Yes |
| Digital watermark | Yes |
| Pixel counter | Yes |
| Password reset via email | Yes |
| Flash log | Yes |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Management features |
|---|
| Web browser | Yes |
| Web-based management | Yes |
| Power |
|---|
| Power source type | Battery, Solar |
| Power consumption (max) | 3.2 W |
| Rechargeable battery | Yes |
| Battery voltage | 10.8 V |
| Battery technology | Lithium |
| Battery capacity | 360 Wh |
| Power consumption (typical) | 2 W |
| DC output voltage | 12 |
| DC output current | 1 A |
| Number of batteries supported | 4 |
| Standby time | 80 day(s) |
| Battery |
|---|
| Rechargeable battery | Yes |
| Battery voltage | 10.8 V |
| Battery technology | Lithium |
| Battery capacity | 360 Wh |
| Number of batteries supported | 4 |
| Battery weight | 3.3 kg |
| Operational conditions |
|---|
| Operating temperature (T-T) | -20 - 60 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Width (with stand) | 882.6 mm |
| Depth (with stand) | 706.3 mm |
| Height (with stand) | 760 mm |
| Package width | 862 mm |
| Package height | 762 mm |
| Package depth | 352 mm |
| Package weight | 36.3 kg |
| Weight (with stand) | 30.2 kg |
| Packaging data |
|---|
| Package width | 862 mm |
| Package height | 762 mm |
| Package depth | 352 mm |
| Package weight | 36.3 kg |
| Sustainability |
|---|
| Compliance certificates | CE, REACH, RoHS, WEEE |
| Packaging content |
|---|
| Number of cameras | 1 |
| Battery included | Yes |
| Technical details |
|---|
| Lens mount interface | M22 |
| Iris | Yes |
| Audio input | 1 |
| Compliance certificates | CE, REACH, RoHS, WEEE |
| Other features |
|---|
| Browser supported | Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
| Audio output | 1 |
