| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 33 |
| Languages support | Multi |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Dynamic range | 140 dB |
| Picture overlay | 128 x 128 pixels |
| Picture overlay | 24 bit |
| Design |
|---|
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling/wall |
| International Protection (IP) code | IP67 |
| Housing material | Aluminium |
| Camera |
|---|
| Minimum illumination | 0 lx |
| Tilt angle range | 0 - 75° |
| Pan range | 0 - 355° |
| Angle of rotation | 355° |
| Camera shutter speed | 1 - 1/100000 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 114.5 - 41.8° |
| Lens viewing angle, vertical | 59.3 - 23.6° |
| Lens viewing angle, diagonal | 141.1 - 48° |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 2.5 |
| Auto focus | Yes |
| Recognize distance (wide) | 12 m |
| Recognize distance (tele) | 29.8 m |
| Observe distance (wide) | 23.8 m |
| Observe distance (tele) | 59.1 m |
| Identify distance (wide) | 6 m |
| Identify distance (tele) | 14.9 m |
| Detect distance (wide) | 60 m |
| Detect distance (tele) | 149 m |
| Minimum aperture number | 1.2 |
| Focus | Motorized/Manual |
| Focal length range | 2.8 - 12 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Image stabilizer | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | 32 Kbps - 8 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
| Maximum resolution | 2560 x 1440 pixels |
| Supported graphics resolutions | 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440 |
| Frame rate | 60 fps |
| Video streaming | Yes |
| Total megapixels | 4 MP |
| Audio |
|---|
| Voice codecs | G.711, G.722.1, G.726, MP2L2, PCM |
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Audio formats supported | MP3 |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 8 - 320 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3at |
| Quality of Service (QoS) support | Yes |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE |
| Client interoperability | iVMS-4200, Hik-Connect |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 20 channels |
| Live view | Yes |
| Storage |
|---|
| Maximum memory card size | 256 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces |
|---|
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Composite video out | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Intelligent Video Surveillance (IVS) system features | Defocus, Face detection, Scene change |
| Video motion detection | Yes |
| Security algorithms | EAP-LEAP, EAP-MD5, EAP-TLS |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Heartbeat | Yes |
| Digital watermark | Yes |
| Anti-flicker | Yes |
| Automatic Network Replenishment (ANR) | Yes |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Management features |
|---|
| Web browser | Yes |
| Web-based management | Yes |
| Reset button | Yes |
| Behavior analysis | Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 14.7 W |
| Power consumption (Power over Ethernet (PoE)) | 15 W |
| Power consumption | 100 mA |
| DC output voltage | 12 |
| DC output current | 1.23 A |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Height | 141.8 mm |
| Diameter | 16.2 cm |
| Weight | 1.49 kg |
| Package width | 251 mm |
| Package height | 189 mm |
| Package depth | 215 mm |
| Package weight | 2.44 kg |
| Packaging data |
|---|
| Package width | 251 mm |
| Package height | 189 mm |
| Package depth | 215 mm |
| Package weight | 2.44 kg |
| Features |
|---|
| Basic event | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, abnormal reboot, HDD full, HDD error), video quality diagnosis, vibration detection |
| Sustainability |
|---|
| Compliance certificates | REACH, RoHS |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Iris | Yes |
| Compliance certificates | REACH, RoHS |
| Other features |
|---|
| Focus | Motorized/Manual |
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
| I/O ports | 1x line in, 1x line out, 3.5 mm |
