| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 33 |
| Languages support | Multi |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Built-in light | Yes |
| Dynamic range | 140 dB |
| Blue glass filter | Yes |
| Open platform version | HEOP 2.0 |
| AI software framework | Caffe, ONNX, PaddlePaddle, TensorFlow |
| Supported programming languages | C++ |
| Design |
|---|
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling/wall |
| Protection features | Dust resistant, Vandal proof, Waterproof |
| International Protection (IP) code | IP67 |
| Housing material | Aluminium |
| Camera |
|---|
| Minimum illumination | 0.0003 lx |
| Tilt angle range | 0 - 75° |
| Pan range | 0 - 355° |
| Angle of rotation | 355° |
| Camera shutter speed | 1 - 1/100000 s |
| Lens viewing angle, horizontal | 111° |
| Lens viewing angle, vertical | 57.6° |
| Lens viewing angle, diagonal | 138.4° |
| Number of Privacy masking areas | 8 |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1 |
| Detect distance | 61.5 m |
| Observe distance | 24.4 m |
| Recognize distance | 12.73 m |
| Identify distance | 6.2 m |
| Fixed focal length | 2.8 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 40 m |
| LED type | IR/White |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Bit rate | 32 Kbps - 8 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
| Maximum resolution | 2688 x 1520 pixels |
| Supported graphics resolutions | 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 2688 x 1520 |
| Frame rate | 30 fps |
| Total megapixels | 4 MP |
| Audio |
|---|
| Voice codecs | AAC, G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, MP3 |
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 8 - 320 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3af |
| Quality of Service (QoS) support | Yes |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, SRTP, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, ARP, WebSocket, WebSockets |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 20 channels |
| Live view | Yes |
| Storage |
|---|
| Maximum memory card size | 1 TB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 40 MB |
| eMMC capacity | 1 GB |
| RAM capacity | 350 MB |
| Ports & interfaces |
|---|
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Intelligent Video Surveillance (IVS) system features | Defocus, Human detection, Intrusion, Line crossing detection, Missing object, People counting, Region entrance detection, Region exiting detection, Scene change, Vehicle detection |
| Video motion detection | Yes |
| Security algorithms | EAP-LEAP, EAP-MD5, EAP-TLS, TLS |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Heartbeat | Yes |
| Digest authentication | Yes |
| Automatic Network Replenishment (ANR) | Yes |
| Audit log | Yes |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Network access storage (NAS) | Yes |
| Management features |
|---|
| Management software | iVMS-4200, Hik-Connect |
| Reset button | Yes |
| Behavior analysis | Audio exception detection |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (Power over Ethernet (PoE)) | 10.2 W |
| Power consumption (typical) | 10.2 W |
| DC output voltage | 12 |
| DC output current | 0.85 A |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Package type | Box |
| Height | 121.5 mm |
| Diameter | 9.76 cm |
| Weight | 620 g |
| Package width | 150 mm |
| Package height | 141 mm |
| Package depth | 150 mm |
| Package weight | 805 g |
| Packaging data |
|---|
| Package type | Box |
| Package width | 150 mm |
| Package height | 141 mm |
| Package depth | 150 mm |
| Package weight | 805 g |
| Sustainability |
|---|
| Sustainability compliance | Yes |
| Compliance certificates | BIS, CB, CE, Electromagnetic Compatibility (EMC), Industry Canada (IC), KC, Low Voltage Directive (LVD), RCM, REACH, RoHS, UL |
| Packaging content |
|---|
| Number of cameras | 1 |
| Package type | Box |
| Technical details |
|---|
| Iris | Yes |
| Sustainability compliance | Yes |
| Compliance certificates | BIS, CB, CE, Electromagnetic Compatibility (EMC), Industry Canada (IC), KC, Low Voltage Directive (LVD), RCM, REACH, RoHS, UL |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
| Browser supported | Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
