| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 8 |
| Languages support | Multi |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Dynamic range | 140 dB |
| Design |
|---|
| IK code | IK10 |
| Form factor | Bullet |
| Product colour | Grey |
| Mounting type | Wall |
| International Protection (IP) code | IP67 |
| Housing material | Aluminium |
| Camera |
|---|
| Minimum illumination | 0 lx |
| Camera shutter speed | 1/2.5 - 1/100000 s |
| Lens viewing angle, horizontal | 15.1 - 41.9° |
| Lens viewing angle, vertical | 8.64 - 22.9° |
| Lens viewing angle, diagonal | 17.3 - 48.8° |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1.7 |
| Auto focus | Yes |
| Focal length range | 8 - 32 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 50 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Noise reduction | Yes |
| Bit rate | 32 Kbps - 16 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.265 |
| Maximum resolution | 2688 x 1520 pixels |
| Video formats supported | H.264, H.265 |
| Supported graphics resolutions | 2688 x 1520, 1920 x 1080 (HD 1080) |
| Supported video modes | 1080p, 1520p |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 4 MP |
| Video recording | Yes |
| Audio |
|---|
| Audio formats supported | G.722.1, G.711 |
| Bit rate range | 8 - 16 Kbit/s |
| Network |
|---|
| Quality of Service (QoS) support | Yes |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Supported network protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,SFTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IGMP,QoS,IPv4/IPv6,UDP,SSL/TLS,ISUP,ARP,802.1X |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 6 channels |
| Live view | Yes |
| Storage |
|---|
| Maximum memory card size | 512 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces |
|---|
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Password protection | Yes |
| Heartbeat | Yes |
| Digital watermark | Yes |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Management features |
|---|
| Web-based management | Yes |
| Reset button | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 15 W |
| Power consumption (Power over Ethernet (PoE)) | 15 W |
| DC output voltage | 24, 12 |
| DC output current | 1.25 A |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 70 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Width | 120 mm |
| Depth | 428.5 mm |
| Height | 132.8 mm |
| Weight | 2.98 kg |
| Package width | 259 mm |
| Package height | 193 mm |
| Package depth | 595 mm |
| Package weight | 4.38 kg |
| Packaging data |
|---|
| Package width | 259 mm |
| Package height | 193 mm |
| Package depth | 595 mm |
| Package weight | 4.38 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Manual | Yes |
| Other features |
|---|
| Video compression formats | H.264, H.265 |
