| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 33 |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Design |
|---|
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White, Black |
| Mounting type | Ceiling |
| LED indicators | Yes |
| International Protection (IP) code | IP67 |
| Camera |
|---|
| Minimum illumination | 0 lx |
| Tilt angle range | 0 - 90° |
| Pan range | 0 - 355° |
| Camera shutter speed | 1/100000 - 1/25 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 102° |
| Lens viewing angle, vertical | 55° |
| Lens viewing angle, diagonal | 120° |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors | 1 |
| Panoramic camera |
|---|
| Viewing angle, vertical (panoramic camera) | 180° |
| Viewing angle, horizontal (panoramic camera) | 95° |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1.4 |
| Detect distance | 91.4 m |
| Observe distance | 36.3 m |
| Recognize distance | 18.3 m |
| Identify distance | 9.1 m |
| Fixed focal length | 2.8 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 20 m |
| LED type | IR/White |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Highlight Compensation (HLC) | Yes |
| Bit rate | 32 Kbps - 16 Mbps |
| Back Light Compensation (BLC) | Yes |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Maximum resolution | 8160 x 3616 pixels |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 3072 x 1728, 3840 x 2160 |
| Supported video modes | 720p, 1080p, 1440p, 2160p |
| Frame rate | 30 fps |
| Total megapixels | 32 MP |
| Video recording | Yes |
| Audio |
|---|
| Audio formats supported | G.711, G.722.1, G.726, MP2L2, PCM |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 16 - 192 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 20 channels |
| Live view | Yes |
| Storage |
|---|
| Maximum memory card size | 128 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces |
|---|
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Security |
|---|
| Mirror | Yes |
| Heartbeat | Yes |
| Anti-flicker | Yes |
| Alarm input channels | 2 |
| Alarm output channels | 2 |
| Management features |
|---|
| Reset button | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 17 W |
| Power consumption (Power over Ethernet (PoE)) | 23 W |
| DC-in jack | Yes |
| DC output voltage | 12 |
| DC output current | 1.4 A |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Width | 190 mm |
| Depth | 208 mm |
| Height | 207 mm |
| Weight | 3.5 kg |
| Package width | 336 mm |
| Package height | 293 mm |
| Package depth | 261 mm |
| Packaging data |
|---|
| Package width | 336 mm |
| Package height | 293 mm |
| Package depth | 261 mm |
| Packaging content |
|---|
| Number of cameras | 1 |
| Mounting kit | Yes |
| Manual | Yes |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+ |
