| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 33 |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Design |
|---|
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White, Black |
| Mounting type | Ceiling |
| LED indicators | Yes |
| International Protection (IP) code | IP67 |
| Camera |
|---|
| Minimum illumination | 0 lx |
| Tilt angle range | 10 - 90° |
| Pan range | -60 - 60° |
| Angle of rotation | 360° |
| Camera shutter speed | 1/100000 - 1 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 31.2 - 102.4° |
| Lens viewing angle, vertical | 17.6 - 54.7° |
| Lens viewing angle, diagonal | 35.8 - 122.1° |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Number of sensors | 4 |
| Lens system |
|---|
| Number of lenses | 4 |
| Maximum aperture number | 1.6 |
| Auto focus | Yes |
| Focus | Motorized/Manual |
| Focal length range | 2.8 - 12 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Maximum resolution | 2688 x 1520 pixels |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 2688 x 1520 |
| Supported video modes | 720p, 1080p, 1440p, 1520p |
| Frame rate | 25 fps |
| Total megapixels | 4 MP |
| Video recording | Yes |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 62 dB |
| Audio formats supported | AAC-LC, G.711, G.722.1, G.726, MP2L2, MP3, PCM |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 16 - 192 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 20 channels |
| Live view | Yes |
| Storage |
|---|
| Maximum memory card size | 1 TB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces |
|---|
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Security |
|---|
| Password protection | Yes |
| Flash log | Yes |
| Alarm input channels | 2 |
| Alarm output channels | 2 |
| Management features |
|---|
| Reset button | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 20 W |
| Power consumption (Power over Ethernet (PoE)) | 23.4 W |
| DC-in jack | Yes |
| DC output voltage | 12 |
| DC output current | 1.67 A |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Height | 148 mm |
| Diameter | 29 cm |
| Weight | 4.7 kg |
| Package width | 453 mm |
| Package height | 385 mm |
| Package depth | 393 mm |
| Package weight | 7.7 kg |
| Packaging data |
|---|
| Package width | 453 mm |
| Package height | 385 mm |
| Package depth | 393 mm |
| Package weight | 7.7 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Mounting kit | Yes |
| Manual | Yes |
| Other features |
|---|
| Focus | Motorized/Manual |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
