| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Languages support | Multi |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Dynamic range | 120 dB |
| Design |
|---|
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling |
| Housing material | Metal |
| Camera |
|---|
| Tilt angle range | 0 - 75° |
| Pan range | 0 - 355° |
| Angle of rotation | 355° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Lens viewing angle, horizontal | 108° |
| Lens viewing angle, vertical | 58° |
| Lens viewing angle, diagonal | 133° |
| Number of Privacy masking areas | 4 |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1.6 |
| Detect distance | 97 m |
| Observe distance | 38 m |
| Recognize distance | 19 m |
| Identify distance | 9 m |
| Fixed focal length | 2.8 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | 32kbps - 16Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Maximum resolution | 3840 x 2160 pixels |
| Supported graphics resolutions | 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520, 3200 x 1800, 3840 x 2160 |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Audio formats supported | AAC-LC, G.711, G.722.1, G.726, MP2L2, MP3, PCM |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 8 - 320 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3af |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 6 channels |
| Storage |
|---|
| Maximum memory card size | 512 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces |
|---|
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Intelligent Video Surveillance (IVS) system features | Face detection, Human detection, Intrusion, Line crossing detection, Region entrance detection, Region exiting detection, Scene change, Vehicle detection |
| Video motion detection | Yes |
| Security algorithms | EAP-LEAP, EAP-MD5, EAP-TLS, TLS |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Heartbeat | Yes |
| Digital watermark | Yes |
| Pixel counter | Yes |
| Password reset via email | Yes |
| Flash log | Yes |
| Digest authentication | Yes |
| Audit log | Yes |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Management features |
|---|
| Reset button | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 10 W |
| DC output voltage | 12 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -10 - 40 °C |
| Storage temperature (T-T) | -10 - 50 °C |
| Weight & dimensions |
|---|
| Height | 90 mm |
| Diameter | 11.9 cm |
| Weight | 440 g |
| Package width | 150 mm |
| Package height | 141 mm |
| Package depth | 150 mm |
| Package weight | 720 g |
| Packaging data |
|---|
| Package width | 150 mm |
| Package height | 141 mm |
| Package depth | 150 mm |
| Package weight | 720 g |
| Sustainability |
|---|
| Compliance certificates | CB, CE, Electromagnetic Compatibility (EMC), KC, Low Voltage Directive (LVD), RCM, RoHS, UKCA, WEEE |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Lens mount interface | M12 |
| Audio input | 1 |
| Compliance certificates | CB, CE, Electromagnetic Compatibility (EMC), KC, Low Voltage Directive (LVD), RCM, RoHS, UKCA, WEEE |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Audio output | 1 |
