| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Fog proof | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Dynamic range | 120 dB |
| Design |
|---|
| Fog proof | Yes |
| Form factor | Dome |
| Product colour | White, Black |
| Mounting type | Ceiling |
| International Protection (IP) code | IP66 |
| Housing material | Plastic |
| Camera |
|---|
| Tilt preset speed | 200 °/sec |
| Pan preset speed | 240 °/sec |
| Minimum illumination | 0 lx |
| Field of view (FOV) angle | 60.2° |
| Tilt angle range | -15 - 90° |
| Pan range | 0 - 360° |
| Camera shutter speed | 1/30000 - 1 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Tilt manual speed | 0.1 - 120 °/sec |
| Pan manual speed | 0 - 160 °/sec |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Panoramic camera |
|---|
| Sensor type (panoramic camera) | CMOS |
| Optical sensor size (panoramic camera) | 25.4 / 2.5 mm (1 / 2.5") |
| Maximum resolution (panoramic camera) | 3632 x 1632 pixels |
| Viewing angle, vertical (panoramic camera) | 80° |
| Viewing angle, horizontal (panoramic camera) | 180° |
| Fixed focal length (panoramic camera) | 2.8 mm |
| Lens system |
|---|
| Maximum aperture number | 1.5 |
| Auto focus | Yes |
| Focus | Motorized/Manual |
| Zoom capability | Yes |
| Optical zoom | 32x |
| Digital zoom | 16x |
| Focal length range | 5.9 - 188.8 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 200 m |
| LED type | IR/White |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Sharpness |
| Privacy masking | Yes |
| Image stabilizer | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Bit rate | 32 Kbps to 16384 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Maximum resolution | 3680 x 1656 pixels |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 1280 x 960, 3632 x 1632, 2560 x 1440, 352 x 288, 352 x 240, 1920 x 1080 (HD 1080), 640 x 480 (VGA), 1280 x 720 (HD 720), 704 x 576 |
| Supported video modes | 1080p, 720p, 480p, 1440p, 960p |
| Frame rate | 25 fps |
| Total megapixels | 6 MP |
| Video recording | Yes |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Audio formats supported | G.722.1, MP2L2, G.726, MP3, AAC-LC, PCM, G.711 |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 8 - 320 Kbit/s |
| Network |
|---|
| Quality of Service (QoS) support | Yes |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Supported network protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv4/IPv6,UDP,Bonjour,WebSocket,WebSockets,SRTP |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 20 channels |
| Live view | Yes |
| Storage |
|---|
| Maximum memory card size | 256 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Security algorithms | EAP-LEAP, EAP-MD5, EAP-TLS |
| IP address filtering | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Digital watermark | Yes |
| Automatic Network Replenishment (ANR) | Yes |
| Alarm input channels | 2 |
| Alarm output channels | 1 |
| Network access storage (NAS) | Yes |
| Management features |
|---|
| Reset button | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 60 W |
| DC output voltage | 24 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 65 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions |
|---|
| Height | 387.2 mm |
| Diameter | 22.2 cm |
| Weight | 6 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Other features |
|---|
| Focus | Motorized/Manual |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
