| Processor |
|---|
| Thermal Design Power (TDP) | 150 W |
| Processor threads | 24 |
| Memory types supported by processor | DDR5-SDRAM |
| Memory clock speeds supported by processor | 4400 MHz |
| Processor cache | 30 MB |
| Processor frequency | 2.4 GHz |
| Processor boost frequency | 4.1 GHz |
| Number of processors installed | 1 |
| Processor model | 4510 |
| System bus rate | 16 GT/s |
| Processor cores | 12 |
| Processor manufacturer | Intel |
| Motherboard chipset | Intel C741 |
| Processor family | Intel Xeon Silver |
| Memory |
|---|
| Internal memory | 32 GB |
| Memory layout (slots x size) | 1 x 32 GB |
| Memory slots | 16x DIMM |
| Maximum internal memory | 1 TB |
| Internal memory type | DDR5-SDRAM |
| Memory data transfer rate | 5600 MT/s |
| Buffered memory type | Registered (buffered) |
| Memory ranking | 2 |
| Storage |
|---|
| Supported RAID controllers | Front PERC H755 Front Load |
| Number of SSDs supported | 8 |
| Total storage capacity | 480 GB |
| SSD interface | SATA III |
| SSD capacity | 480 GB |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| Hot-Plug support | Yes |
| SSD size | 2.5" |
| Drive writes per day (DWPD) | 1 |
| Supported SSD sizes | 3.5" |
| Storage drive adapter included | Yes |
| Storage drive adapter type | 2.5" - 3.5" |
| Graphics |
|---|
| Thermal Design Power (TDP) | 150 W |
| Network |
|---|
| LAN controller | Broadcom 5720 |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| Optical drive |
|---|
| Optical drive type | No |
| Design |
|---|
| Optical drive type | No |
| Chassis type | Tower (4.5U) |
| Product colour | Black |
| Bezel | Yes |
| Performance |
|---|
| Compatible operating systems | Canonical® Ubuntu® Server LTS Microsoft® Windows Server® with Hyper-V RedHat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi® |
| Remote administration | iDRAC9, Enterprise 16G |
| Operating system installed | No |
| Software |
|---|
| Compatible operating systems | Canonical® Ubuntu® Server LTS Microsoft® Windows Server® with Hyper-V RedHat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi® |
| Operating system installed | No |
| Power |
|---|
| Number of redundant power supplies installed | 2 |
| Redundant power supply (RPS) support | Yes |
| Power supply | 1100 W |
| Certificates |
|---|
| 80 PLUS certification | 80 PLUS Titanium |
| Management features |
|---|
| Remote administration | iDRAC9, Enterprise 16G |
| Sustainability |
|---|
| Total carbon footprint (kg of CO2e) | 5989 |
| Carbon footprint |
|---|
| Total carbon footprint (kg of CO2e) | 5989 |
| Total carbon emissions, standard deviation (kg of CO2e) | 3189 |
| PAIA version | PAIA 1.3.2, 2022 |
| Carbon emissions, energy usage (kg of CO2e) | 5210.43 |
| Carbon emissions, manufacturing (kg of CO2e) | 419.23 |
| Carbon emissions, logistics (kg of CO2e) | 299.45 |
| Carbon emissions, end-of-life (kg of CO2e) | 59.89 |
| Technical details |
|---|
| Hot-Plug support | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Chassis type | Tower (4.5U) |
| Packaging content | UK Power Cord, 2M, C13, 250V, 10 Amps |
| Supported RAID configuration | Unconfigured RAID for HDDs or SSDs (Mixed Drive Types Allowed) |
| Weight & dimensions |
|---|
| Width | 200 mm |
| Packaging content |
|---|
| Packaging content | UK Power Cord, 2M, C13, 250V, 10 Amps |
| Other features |
|---|
| Data transfer rate | 6 Gbit/s |
| Bytes per sector | 512e |
| Target workload | Read Intensive (RI) |
| Open Compute Project (OCP) | NIC 3.0 |
