| Processor |
|---|
| Processor generation | 1st Generation Intel® Xeon® Scalable |
| Thermal Design Power (TDP) | 140 W |
| Tcase | 91 °C |
| Supported instruction sets | AVX, AVX 2.0, AVX-512, SSE4.2 |
| Stepping | H0 |
| Scalability | S4S |
| Processor threads | 36 |
| Processor package size | 76.0 x 56.5 mm |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Skylake |
| Processor code | SR3AX |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Maximum number of PCI Express lanes | 48 |
| Maximum internal memory supported by processor | 768 GB |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| Processor cache type | L3 |
| Processor cache | 24.75 MB |
| Conflict-Free processor | Yes |
| Processor frequency | 2.3 GHz |
| Processor boost frequency | 3.7 GHz |
| Number of processors installed | 2 |
| Processor model | 6140 |
| Supported processor sockets | LGA 3647 (Socket P) |
| Processor socket | LGA 3647 (Socket P) |
| Processor cores | 18 |
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® |
| Memory |
|---|
| Internal memory | 128 GB |
| Memory slots | 16x DIMM |
| Memory clock speed | 2666 MHz |
| Maximum internal memory | 512 GB |
| Internal memory type | DDR4-SDRAM |
| Storage |
|---|
| RAID support | Yes |
| RAID levels | 0, 1, 1 ADM, 5, 6, 10 |
| Optical drive type | No |
| HDD size | 2.5" |
| HDD interface | Serial ATA, Serial Attached SCSI (SAS) |
| Network |
|---|
| Ethernet LAN | Yes |
| Ethernet interface type | 20 Gigabit Ethernet |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Expansion slots |
|---|
| PCI Express slots version | 3.0 |
| Optical drive |
|---|
| Optical drive type | No |
| Design |
|---|
| Optical drive type | No |
| Chassis type | Blade |
| Product colour | Black, Metallic |
| Performance |
|---|
| Compatible operating systems | Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Canonical Ubuntu Oracle Solaris VMware Citrix XenServer |
| Operating system installed | No |
| Software |
|---|
| Compatible operating systems | Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Canonical Ubuntu Oracle Solaris VMware Citrix XenServer |
| Operating system installed | No |
| Processor special features |
|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 1.00 |
| Processor ARK ID | 120485 |
| Technical details |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Supported processor sockets | LGA 3647 (Socket P) |
| Ethernet interface type | 20 Gigabit Ethernet |
| Chassis type | Blade |
| Sustainability certificates | ENERGY STAR |
| Sustainability |
|---|
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions |
|---|
| Width | 55.4 mm |
| Weight | 6.35 kg |
| Height | 180.3 mm |
| Depth | 517.4 mm |
