| Display |
|---|
| Panel type | TFT-LCD |
| Display number of colours | 16.7 million colours |
| Number of simultaneous touchpoints | 10 |
| Touchscreen | Yes |
| Active display area (W x H) | 217 x 136 mm |
| Display technology | LED |
| Display diagonal | 25.6 cm (10.1") |
| Display resolution | 1920 x 1200 pixels |
| Display brightness | 450 cd/m² |
| HD type | Full HD+ |
| Response time | 30 ms |
| Contrast ratio (typical) | 900:1 |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 160° |
| Number of displays | 1 |
| Touchscreen technology | Projected capacitive system |
| Native refresh rate | 60 Hz |
| Multi-touch | Yes |
| Ports & interfaces |
|---|
| USB connector type | USB Type-A, USB Type-C |
| USB port | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Wi-Fi | Yes |
| DC-in jack | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| USB ports quantity | 2 |
| Audio |
|---|
| Number of built-in speakers | 2 |
| RMS rated power | 1.5 W |
| Built-in speaker(s) | Yes |
| Design |
|---|
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Stainless steel |
| Panel mounting interface | 75 x 75 mm |
| Certification | UL/cUL (US) FCC (US) IC (Canada) CE (Europe) CB (International) VCCI, MIC (Japan) RCM (Australia) |
| VESA mounting | Yes |
| Screen shape | Flat |
| Performance |
|---|
| Purpose | Commercial |
| Mean time between failures (MTBF) | 50000 h |
| Number of microphones | 2 |
| Wi-Fi | Yes |
| Power |
|---|
| Power consumption (sleep) | 2 W |
| Power consumption (off) | 0.2 W |
| Power consumption (typical) | 6 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Computer system |
|---|
| Processor cores | 8 |
| Operating system installed | Android |
| Internal memory | 8 GB |
| Internal storage capacity | 64 GB |
| Processor manufacturer | Qualcomm |
| Built-in processor | Yes |
| Operating system version | Android 14 |
| Weight & dimensions |
|---|
| Display width | 262.6 mm |
| Display depth | 32.5 mm |
| Display height | 179.4 mm |
| Display weight | 1.3 kg |
| Packaging data |
|---|
| Package width | 353 mm |
| Package depth | 173 mm |
| Package height | 20 mm |
| Package weight | 2.8 kg |
| Cables included | Power |
| Packaging content |
|---|
| Cables included | Power |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 50 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Certificates |
|---|
| Certification | UL/cUL (US) FCC (US) IC (Canada) CE (Europe) CB (International) VCCI, MIC (Japan) RCM (Australia) |
| Technical details |
|---|
| VESA mounting | Yes |
| USB connector type | USB Type-A, USB Type-C |
| Panel type | TFT-LCD |
| Number of simultaneous touchpoints | 10 |
| Network |
|---|
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Thin Client |
|---|
| Operating system installed | Android |
| Internal memory | 8 GB |
| Internal storage capacity | 64 GB |
| Other features |
|---|
| USB connector type | USB Type-A, USB Type-C |
| Panel type | TFT-LCD |
| Number of simultaneous touchpoints | 10 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Wi-Fi | Yes |
| Megapixel (approx.) | 8 MP |
| Mean time between failures (MTBF) | 50000 h |
| Display technology | LED |
| DC-in jack | Yes |
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Aspect ratio | 16:10 |
