| Display |
|---|
| Panel type | IPS |
| Display number of colours | 16.7 million colours |
| Number of simultaneous touchpoints | 15 |
| Touchscreen | Yes |
| Active display area (W x H) | 1212 x 683 mm |
| Display technology | LED |
| Display diagonal | 139.7 cm (55") |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Response time | 8 ms |
| Contrast ratio (typical) | 1100:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.315 x 0.315 mm |
| Display diagonal (metric) | 139 cm |
| Native aspect ratio | 16:9 |
| Horizontal scan range | 30 - 83 kHz |
| Anti-glare screen | Yes |
| Colour depth | 8 bit |
| Maximum refresh rate | 60 Hz |
| Touchscreen technology | Projected capacitive system |
| Surface hardness | 7H |
| Native refresh rate | 60 Hz |
| Glass thickness | 4 mm |
| Ports & interfaces |
|---|
| DisplayPort version | 1.2 |
| HDMI version | 1.4/2.0 |
| RS-232C | Yes |
| DisplayPorts quantity | 1 |
| Ethernet LAN | Yes |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio |
|---|
| Number of built-in speakers | 2 |
| RMS rated power | 16 W |
| Built-in speaker(s) | Yes |
| Design |
|---|
| Placement supported | Horizontal/Vertical |
| Housing material | Metal |
| Bezel width (top) | 3.32 cm |
| Bezel width (side) | 2.97 cm |
| Bezel width (bottom) | 3.32 cm |
| Product colour | White |
| Panel mounting interface | 600 x 400 mm |
| VESA mounting | Yes |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Bezel colour | White |
| Wall mountable | Yes |
| Performance |
|---|
| Operating hours (hours/days) | 24/7 |
| International Protection (IP) code | IP54 |
| Mean time between failures (MTBF) | 50000 h |
| On Screen Display (OSD) languages | German, English, Spanish, French, Italian, Dutch, Polish, Russian |
| On Screen Display (OSD) | Yes |
| HDCP | Yes |
| Power |
|---|
| Power consumption (off) | 0.3 W |
| Power consumption (typical) | 155 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| Weight & dimensions |
|---|
| Width (with stand) | 1271.5 mm |
| Height (with stand) | 749.4 mm |
| Depth (with stand) | 68 mm |
| Width | 1271.5 mm |
| Depth | 68 mm |
| Height | 749.4 mm |
| Weight | 41 kg |
| Weight (with stand) | 41 kg |
| Display width | 1271.5 mm |
| Display depth | 68 mm |
| Display height | 749.4 mm |
| Display weight | 41 kg |
| Packaging data |
|---|
| Package width | 1400 mm |
| Package depth | 245 mm |
| Package height | 930 mm |
| Package weight | 46.5 kg |
| Quick start guide | Yes |
| Cables included | AC, USB, HDMI, DisplayPort |
| Packaging content |
|---|
| Quick start guide | Yes |
| Cables included | AC, USB, HDMI, DisplayPort |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Technical details |
|---|
| VESA mounting | Yes |
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Power supply type | Internal |
| Panel type | IPS |
| DisplayPort version | 1.2 |
| Depth (without stand) | 68 mm |
| Number of simultaneous touchpoints | 15 |
| Weight (without stand) | 41 kg |
| Height (without stand) | 749.4 mm |
| Audio in (mini jack) | Yes |
| Weight (with stand) | 41 kg |
| User controls | picture (backlight, contrast, brightness, sharpness, H/V-position, phase, Chroma, adjust screen, colour temp., picture mode), sound (treble, bass, balance, volume, mute, speaker, audio source), screen (aspect, Touch feature, reset), settings (OSD time, OSD H/V position, language, schedule, power save, control setting, network setting, advanced, information, all reset) |
| Sustainability certificates | ErP |
| Pallet net width | 142 cm |
| Pallet net height | 124.5 cm |
| Pallet net length | 198.6 cm |
| Compliance certificates | CE, cULus, EAC, REACH, RoHS, UKCA, WEEE |
| Network |
|---|
| Ethernet LAN | Yes |
| Logistics data |
|---|
| Products per pallet | 10 pc(s) |
| Harmonized System (HS) code | 85285210 |
| Features |
|---|
| Harmonized System (HS) code | 85285210 |
| Wall mountable | Yes |
| Other features |
|---|
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Power supply type | Internal |
| Panel type | IPS |
| DisplayPort version | 1.2 |
| Housing material | Metal |
| Depth (without stand) | 68 mm |
| Number of simultaneous touchpoints | 15 |
| Weight (without stand) | 41 kg |
| Height (without stand) | 749.4 mm |
| Width (with stand) | 1271.5 mm |
| Viewable size, vertical | 68.3 cm |
| Viewable size, horizontal | 121.2 cm |
| Mean time between failures (MTBF) | 50000 h |
| Height (with stand) | 749.4 mm |
| Display technology | LED |
| Digital horizontal frequency | 30 - 83 kHz |
| Depth (with stand) | 68 mm |
| Built-in microphone | No |
| Built-in camera | No |
| Bezel width (top) | 3.32 cm |
| Bezel width (side) | 2.97 cm |
| Bezel width (bottom) | 3.32 cm |
| Audio output | 1 |
| Audio input | Yes |
| Quick start guide | Yes |
| Weight (with stand) | 41 kg |
| Maximum refresh rate | 60 Hz |
