SKU: BGM2200-GR  |   Brand: APC

APC BGM2200-GR uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1320 W 6 AC outlet(s)

SKU: BGM2200-GR  |   Brand: APC

APC BGM2200-GR uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1320 W 6 AC outlet(s)

0 in stock

£322.48 ex. VAT

Figures are exclusive of VAT.



APC BGM2200-GR. UPS topology: Line-Interactive, Output power capacity: 2.2 kVA, Output power: 1320 W. AC outlet types: C13 coupler, AC outlets quantity: 6 AC outlet(s), Serial interface type: RJ-45. Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 24 V, Battery life (max): 5 year(s). Form factor: Tower, Product colour: White, Rack capacity: 0U. Certification: IEC 62040-1-1 IEC 62040-2

Product colour White
Output power 1000W to 1500W
UPS topology Line-interactive
Form factor Tower
Weight 14,520.00kg

Power
Output power1320 W
Input operation voltage (min)168 V
Input operation voltage (max)302 V
Output operation voltage (max)230 V
Surge energy rating1080 J
Maximum current12 A
Output power capacity2.2 kVA
Ports & interfaces
Cable length1.52 m
USB portYes
Serial interface typeRJ-45
Cabling technology10/100/1000Base-T(X)
AC outlets quantity6 AC outlet(s)
AC outlet typesC13 coupler
Performance
Audible alarm modesAlarm when on battery, Low battery alarm, Overload alarm
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Response time8 ms
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresNetwork
Noise level45 dB
Audible alarm(s)Yes
Features
Output frequency60 Hz
Audible alarm modesAlarm when on battery, Low battery alarm, Overload alarm
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Response time8 ms
Output power1320 W
Input operation voltage (min)168 V
Input operation voltage (max)302 V
Output operation voltage (max)230 V
Surge energy rating1080 J
Maximum current12 A
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresNetwork
Noise level45 dB
Audible alarm(s)Yes
Output power capacity2.2 kVA
Input frequency50/60 Hz
Battery
Battery life (max)5 year(s)
Number of batteries supported1
Battery voltage24 V
Battery technologySealed Lead Acid (VRLA)
Battery recharge time16 h
Cold startYes
Automatic battery testYes
Design
International Protection (IP) codeIP20
Rack capacity0U
Form factorTower
Product colourWhite
CertificationIEC 62040-1-1 IEC 62040-2
Cable length1.52 m
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3048 m
Non-operating altitude0 - 3048 m
Technical details
Output frequency60 Hz
Sustainability certificatesGreen Premium
Certificates
CertificationIEC 62040-1-1 IEC 62040-2
Packaging content
Cables includedUSB cable
ManualYes
Sustainability
Sustainability certificatesGreen Premium
Weight & dimensions
Package width355 mm
Package depth480 mm
Package height155 mm
Weight12.3 kg
Width104.1 mm
Package weight14.5 kg
Height292.1 mm
Depth408.9 mm
Packaging data
Cables includedUSB cable
ManualYes
Package width355 mm
Package depth480 mm
Package height155 mm
Package weight14.5 kg
