| Power |
|---|
| Input power factor | 0.98 |
| Output power | 2700 W |
| Input operation voltage (min) | 190 V |
| Input operation voltage (max) | 300 V |
| Output operation voltage (min) | 208 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 370 J |
| Maximum current | 13.04 A |
| Emergency Power Off (EPO) | Yes |
| Power factor | 0.9 |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Crest factor | 3:1 |
| Output power capacity | 3 kVA |
| Charging current | 1.5 A |
| Efficiency (ECO mode) | 95% |
| Ports & interfaces |
|---|
| Cable length | 1.5 m |
| Emergency Power Off (EPO) connector | Yes |
| USB port | Yes |
| AC outlets quantity | 8 AC outlet(s) |
| AC outlet types | C13 coupler, C19 coupler, Terminal |
| Power plug | C20 coupler |
| Performance |
|---|
| Audible alarm modes | Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm |
| UPS topology | Double-conversion (Online) |
| Waveform | Pure sine |
| Number of input phases | 1 |
| Response time | 0 ms |
| EMI/RFI noise filtering | Yes |
| Surge protection | Yes |
| Power protection features | Input fuse, Over current, Overload, Short circuit |
| Audible alarm(s) | Yes |
| Features |
|---|
| Output frequency | 50/60 Hz |
| Country of origin | China |
| Audible alarm modes | Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm |
| UPS topology | Double-conversion (Online) |
| Waveform | Pure sine |
| Number of input phases | 1 |
| Input power factor | 0.98 |
| Response time | 0 ms |
| Output power | 2700 W |
| Input operation voltage (min) | 190 V |
| Input operation voltage (max) | 300 V |
| Output operation voltage (min) | 208 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 370 J |
| Maximum current | 13.04 A |
| EMI/RFI noise filtering | Yes |
| Surge protection | Yes |
| Emergency Power Off (EPO) | Yes |
| Power protection features | Input fuse, Over current, Overload, Short circuit |
| Power factor | 0.9 |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Crest factor | 3:1 |
| Audible alarm(s) | Yes |
| Output power capacity | 3 kVA |
| Efficiency (ECO mode) | 95% |
| Input frequency | 50/60 Hz |
| Charging current | 1.5 A |
| Battery |
|---|
| Number of batteries supported | 3 |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 4 h |
| Typical backup time at half load | 13.1 min |
| Typical backup time at full load | 4.3 min |
| Charging current | 1.5 A |
| Replacement battery cartridge | BPSE72V40A |
| Design |
|---|
| Country of origin | China |
| Form factor | Tower |
| Product colour | Black |
| Cable length | 1.5 m |
| Housing material | Metal |
| Display type | LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 1500 m |
| Non-operating altitude | 0 - 1500 m |
| Technical details |
|---|
| Output frequency | 50/60 Hz |
| Harmonized System (HS) code | 8504408590 |
| Compliance certificates | CE, RoHS |
| Certificates |
|---|
| Compliance certificates | CE, RoHS |
| Weight & dimensions |
|---|
| Package width | 295 mm |
| Package depth | 519 mm |
| Package height | 458 mm |
| Weight | 26 kg |
| Width | 169 mm |
| Package weight | 30.4 kg |
| Height | 337 mm |
| Depth | 416 mm |
| Packaging data |
|---|
| Package width | 295 mm |
| Package depth | 519 mm |
| Package height | 458 mm |
| Package weight | 30.4 kg |
| Logistics data |
|---|
| Country of origin | China |
| Harmonized System (HS) code | 8504408590 |
