SKU: 5P1550GR-LBS  |   Brand: Eaton

Eaton 5P1550GR-LBS uninterruptible power supply (UPS) Line-Interactive 1.55 kVA 1100 W 6 AC outlet(s)

SKU: 5P1550GR-LBS  |   Brand: Eaton

Eaton 5P1550GR-LBS uninterruptible power supply (UPS) Line-Interactive 1.55 kVA 1100 W 6 AC outlet(s)

0 in stock

£1,597.07 ex. VAT

Figures are exclusive of VAT.



Eaton 5P UPS, Global, 1U UPS, 1550 VA, 1100W, Input: (1) C14, Outputs: (6) C13, Rackmount/Wallmount, Lithium-ion battery, true sine wave, network card optional, with BS input cord

UPS topology Line-interactive
Form factor Rackmount
Output power 1000W to 1500W
Weight 0.02kg

Power
Output power1100 W
Input operation voltage (min)150 V
Input operation voltage (max)294 V
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Efficiency97%
Power factor1
Output power capacity1.55 kVA
Performance
UPS topologyLine-Interactive
Noise level45 dB
Features
Output frequency50/60 Hz
UPS topologyLine-Interactive
Output power1100 W
Input operation voltage (min)150 V
Input operation voltage (max)294 V
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Efficiency97%
Power factor1
Noise level45 dB
Output power capacity1.55 kVA
Input frequency47/70 Hz
Heat dissipation113 BTU/h
Ports & interfaces
USB portYes
AC outlets quantity6 AC outlet(s)
AC outlet typesC13 coupler
Power plugC13 coupler
RS-232 ports1
Battery
Battery technologyLithium-Ion (Li-Ion)
Typical backup time at half load11 min
Typical backup time at full load4 min
Design
Rack capacity1U
Form factorRackmount
Product colourBlack, Silver
Control typeButtons
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 90%
Operating altitude1 - 3000 m
Technical details
Output frequency50/60 Hz
Compliance certificatesCE, Federal Communications Commission (FCC), IECEx, RoHS, cUL, cULus
Certificates
Compliance certificatesCE, Federal Communications Commission (FCC), IECEx, RoHS, cUL, cULus
Packaging content
Quick installation guideYes
Cables includedInput power cable, RS-232, USB cable
Weight & dimensions
Weight15.8 kg
Width436 mm
Height43 mm
Depth553 mm
Packaging data
Quick installation guideYes
Cables includedInput power cable, RS-232, USB cable
