Teleproject UK


SKU: 9PX2200IRTN-L  |   Brand: Eaton

Eaton 9PX 2200i RT2U Netpack uninterruptible power supply (UPS) Double-conversion (Online) 2.2 kVA 2200 W 10 AC outlet(s)

SKU: 9PX2200IRTN-L  |   Brand: Eaton

Eaton 9PX 2200i RT2U Netpack uninterruptible power supply (UPS) Double-conversion (Online) 2.2 kVA 2200 W 10 AC outlet(s)

0 in stock

£2,004.00 ex. VAT

Figures are exclusive of VAT.



Form factor Rackmount
Output power 2000W to 3000W
UPS topology Double-conversion (Online)
Output power capacity 1200VA to 4000VA
Weight 25,000.00kg

Power
Output power factor1
Input power factor0.99
Output power2200 W
Input operation voltage (min)176 V
Input operation voltage (max)276 V
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Efficiency93.5%
Output power capacity2.2 kVA
Ports & interfaces
Cable length1.8 m
USB portYes
AC outlets quantity10 AC outlet(s)
AC outlet typesC13 coupler, C19 coupler
Power plugC20 coupler
USB 2.0 ports quantity1
RS-232 ports1
Performance
UPS topologyDouble-conversion (Online)
WaveformPure sine
Number of input phases1
LED indicatorsStatus
Noise level40 dB
Features
Output frequency50/60 Hz
UPS topologyDouble-conversion (Online)
WaveformPure sine
Number of input phases1
Output power factor1
Input power factor0.99
Output power2200 W
Input operation voltage (min)176 V
Input operation voltage (max)276 V
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Efficiency93.5%
Noise level40 dB
Output power capacity2.2 kVA
Input frequency40/70 Hz
Battery
Battery technologyLithium-Ion (Li-Ion)
Design
Rack capacity2U
Form factorRackmount
LED indicatorsStatus
Product colourBlack, Silver
CertificationIEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2, FCC Class B, CISPR22 Class B, CE /CB report (TUV) / cULus / EAC /RCM / KC
Cable length1.8 m
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 96%
Technical details
Output frequency50/60 Hz
Sustainability complianceYes
Sustainability certificatesENERGY STAR
Harmonized System (HS) code85078000
Weight & dimensions
Weight25 kg
Width440 mm
Height86.5 mm
Depth605 mm
Packaging data
Rack mount kitYes
Management card includedYes
Logistics data
Harmonized System (HS) code85078000
Certificates
CertificationIEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2, FCC Class B, CISPR22 Class B, CE /CB report (TUV) / cULus / EAC /RCM / KC
Packaging content
Rack mount kitYes
