Data transmission |
---|
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Maximum data transfer rate | 1900 Mbit/s |
Performance |
---|
2.4 GHz | Yes |
5 GHz | Yes |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
Bandwidth | 5 GHz |
VLAN support | Yes |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Channel bandwidth | 160 MHz |
Certification | FCC, UL, RoHS |
Maximum data transfer rate | 1900 Mbit/s |
MIMO type | Single User MIMO |
MIMO | Yes |
Network |
---|
Internal | No |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
Bandwidth |
---|
Bandwidth | 5 GHz |
Channel bandwidth | 160 MHz |
Security |
---|
Cable lock slot | Yes |
Security algorithms | AES, EAP-SIM, EAP-TLS, EAP-TTLS, TKIP, WEP, WPA, WPA2-Enterprise, WPA2-PSK |
Wireless Intrusion Detection System (WIDS) | Yes |
Management features |
---|
VLAN support | Yes |
Certificates |
---|
Certification | FCC, UL, RoHS |
Features |
---|
2.4 GHz | Yes |
5 GHz | Yes |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
Bandwidth | 5 GHz |
VLAN support | Yes |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Channel bandwidth | 160 MHz |
Maximum data transfer rate | 1900 Mbit/s |
Maximal-Ratio Combining (MRC) | Yes |
MIMO type | Single User MIMO |
MIMO | Yes |
Virtual LAN features | Tagged VLAN |
Ports & interfaces |
---|
Ethernet LAN (RJ-45) ports | 1 |
DC-in jack | Yes |
Power |
---|
Power consumption (max) | 20 W |
Power over Ethernet (PoE) | Yes |
AC input voltage | 37 V |
Design |
---|
Placement | Ceiling, Floor, Wall, Window |
Product colour | White |
Internal | No |
LED indicators | Power |
Certification | FCC, UL, RoHS |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Technical details |
---|
Harmonized System (HS) code | 85176990 |
Indication |
---|
LED indicators | Power |
Software |
---|
Maximal-Ratio Combining (MRC) | Yes |
Weight & dimensions |
---|
Width | 268 mm |
Depth | 43 mm |
Weight | 1.09 kg |
Height | 160 mm |
Packaging data |
---|
Mounting kit | Yes |
Packaging content |
---|
Mounting kit | Yes |
Operational conditions |
---|
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 0 - 40 °C |
Logistics data |
---|
Harmonized System (HS) code | 85176990 |
