SKU: CX4631-3906  |   Brand: Socket Mobile

Socket Mobile XtremeScan Mag 641 Handheld bar code reader 1D/2D Green, Black

SKU: CX4631-3906  |   Brand: Socket Mobile

Socket Mobile XtremeScan Mag 641 Handheld bar code reader 1D/2D Green, Black

0 in stock

£480.40 ex. VAT

Figures are exclusive of VAT.



XtremeScan Mag 641

The XtremeScan Mag 641 pairs a rugged barcode scanner with a secure magnetic mounting system to create a versatile, high-performance tool for industrial workflows. Designed for fast-paced environments such as warehousing, logistics, and field service, the 641 supports efficient and consistent data capture throughout the workday. With a reliable scan range of up to 20 inches, the 641 is well suited for close to mid-range scanning tasks including order picking, shelf labeling, package processing, and asset verification. Its omnidirectional scanning engine enables rapid reads from any angle, and the integrated precision aimer supports accurate targeting in a variety of lighting conditions. The IP67-rated housing protects the scanner from dust, water, and accidental drops, ensuring dependable performance in challenging environments. The magnetic attachment system keeps the mobile device firmly in place during use while allowing quick detachment for device access or other mobile tasks. Bluetooth® Low Energy connectivity maintains a stable and power-efficient pairing to iOS, Android, and Windows devices, while the scanner’s high-capacity battery provides full-shift operation.

Connectivity technology Wireless
Power source type Battery
Scanner type 1D/2D
Type Handheld bar code reader
Standard interfaces Bluetooth

Scanning
TypeHandheld bar code reader
Linear (1D) barcodes supportedCodabar, Code 128, Code 39, Code 93, EAN-13, JAN-13, EAN-8, JAN-8, GS1 DataBar Expanded, GS1 Databar Limited, GS1 DataBar Omnidirectional, Interleaved 2 of 5, Trioptic, UPC-A, UPC-E, AusPost, Japanese Post, RM4SCC / KIX, Planet, POSTNET
2D (matrix & stacked) barcodes supportedAztec Code, Composite Codes, Data Matrix, DotCode, Han Xin, MaxiCode, MicroPDF417, Micro QR Code, PDF417, QR Code
Scanner type1D/2D
Light levels (direct sunlight)0 - 100000 lx
Working distance range15 - 509 mm
Ports & interfaces
Connectivity technologyWireless
Bluetooth Low Energy (BLE)Yes
Standard interfacesBluetooth
Performance
Protection featuresDustproof, Water resistant, Drop proof, Waterproof
LED indicatorsYes
International Protection (IP) codeIP67
Product colourGreen, Black
CertificationMIL-STD-810G
Country of originChina
Print contrast25%
Light levels (direct sunlight)0 - 100000 lx
Design
TypeHandheld bar code reader
Protection featuresDustproof, Water resistant, Drop proof, Waterproof
LED indicatorsYes
International Protection (IP) codeIP67
Product colourGreen, Black
CertificationMIL-STD-810G
Power
Power source typeBattery
Charging time7 h
Battery voltage3.7 V
Battery technologyLithium-Ion (Li-Ion)
Battery capacity1200 mAh
Weight & dimensions
Width91 mm
Depth193.1 mm
Height193.1 mm
Technical details
TypeHandheld bar code reader
Protection featuresDustproof, Water resistant, Drop proof, Waterproof
LED indicatorsYes
Windows operating systems supportedYes
Mobile operating systems supportediOS, Android
International Protection (IP) codeIP67
Product colourGreen, Black
CertificationMIL-STD-810G
Compliance certificatesRoHS, Federal Communications Commission (FCC), Telecom Engineering Center (TELEC)
Packaging data
Cables includedUSB
Operational conditions
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)0 - 95%
Drop resistance3.1 m
Light levels (direct sunlight)0 - 100000 lx
Battery
Battery technologyLithium-Ion (Li-Ion)
Battery capacity1200 mAh
Battery weight22 g
Battery capacity4.44 Wh
Number of battery cells1
Packaging content
Cables includedUSB
Other features
Resolution1280 x 960 pixels
Windows operating systems supportedYes
Mobile operating systems supportediOS, Android
