Epson EB-775F

SKU: V11HA83180  |   Brand: Epson

Epson EB-775F

3 in stock

£1,418.90 ex. VAT

Figures are exclusive of VAT.



Digital signage solution
The EB-775F is a cost effective way to create large, informative and immersive displays on multiple surfaces and in tight spaces at full HD and up to 4,100 lumens.

It is designed to display visitor and customer information (e.g. in hospitality, retail and offices), exhibition information - even projecting directly onto exhibits - and boardroom presentations or school lessons.

Create enaging displays
Epson's advanced laser technology makes this a flexible and easy to use digital signage solution. Create enaging displays up to 150" (larger when using 2 devices) at up to 4,100 lumens for easy visibility in bright environments.

Bring any surface to life, discretely
The EB-775F can be installed on wall or ceiling and can project onto almost any surface (even unconventional surfaces such as floor or pillars). It's UST design also makes it ideal for projecting large images in tight spaces. Choose between a black (EB-775F) or white (EB-770F) model to discretely blend it into your environment - it can even be hidden to create floating and borderless displays to surprise and delight audiences.

Robust, reliable and cost effective
Our laser technology is also robust and low maintenance. Offering up to 20,000 hours maintenance-free use and a 5 year warranty, this is a fit-and-forget display solution you can rely on at a cost-effective price.

Flexible playback options
Epson offers free apps for content creation (Epson Creative Projection & Epson Projector Content Management). Content can be played directly from USB (including playlists, videos, and signage content) via the built-in playback feature, or users can upload and playback content wirelessly with built-in Wi-Fi and Miracast.

Product type Ultra short throw projector
Light source type Laser
Native aspect ratio 16:9
Projector native resolution 1080p (1920x1080)
Weight 4000g to 6000g
VGA (D-Sub) ports quantity 2
Projector brightness Over 4000 ansi Lumens
DVI port N
HDMI ports quantity 3
Projection technology 3LCD
Noise level 30dB to 40dB
Weight 8,669.00kg

Projector
Number of colours1.07 billion colours
Projector native resolution1080p (1920x1080)
Projection distance (wide)0 - 0.4 m
Projection distance (tele)0 - 0.7 m
Native aspect ratio16:9
Supported aspect ratios16:9, 21:9
Screen size compatibility1524 - 3810 mm (60 - 150")
Contrast ratio (typical)2500000:1
Contrast ratio (dynamic)5000000:1
Zoom ratio1.35:1
Zoom capabilityYes
Vertical scan range192 - 240 Hz
Projector brightness (economic mode)2800 ANSI lumens
Keystone correction, vertical±3°
Keystone correction, horizontal±3°
Projection technology3LCD
Projector brightness4100 ANSI lumens
Heat dissipation895 BTU/h
Lamps
Light source typeLaser
Service life of light source20000 h
Service life of light source (economic mode)30000 h
Light source
Light source typeLaser
Service life of light source20000 h
Service life of light source (economic mode)30000 h
Lens system
Zoom ratio1.35:1
Zoom capabilityYes
FocusManual
Focal length range3.7 mm
Throw ratio0.25 - 0.35:1
F-number (relative aperture)1.6
Scanning frequency
Vertical scan range192 - 240 Hz
Video
Video processing10 bit
Video colour modesBlackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Presentation, sRGB
Full HDYes
Supported video modes1080p
Audio
Built-in speaker(s)Yes
Number of built-in speakers1
RMS rated power16 W
Ports & interfaces
USB 2.0 Type-B ports quantity1
VGA (D-Sub) ports quantity2
HDMI ports quantity3
Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity1
Audio (L/R) in2
Audio (L/R) out1
Serial interface typeRS-232C
DVI portNo
AC (power) inYes
Network
Ethernet LANYes
Wi-FiYes
Ethernet LAN (RJ-45) ports1
MiracastYes
Storage
Card reader integratedNo
Sound emission
Noise level37 dB
Noise level (economic mode)27 dB
Technical details
Product colourBlack
Security featuresKensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
Option typeAir filter, Ceiling mount, Connection and control box, External Speaker, Safety wire set, Visualiser camera, WP System - ELPWP10, Wall hanging bracket, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01
Heat dissipation895 BTU/h
Control panel0.61 inch with C2 Fine
Box contentsPower cable, Quick Start Guide, Remote control incl. batteries, User guide, Warranty Documents
Products per pallet12 pc(s)
Quantity per pack1 pc(s)
Pallet gross width80 cm
Pallet gross length120 cm
Pallet gross height2.07 m
Products per pallet layer (UK)4 pc(s)
Products per pallet layer2 pc(s)
Products per pallet (UK)24 pc(s)
Pallet length (UK)120 cm
Pallet height (UK)2.07 m
Other features21:9 aspect ratio support, A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Edge Blending, Email notification, Home Screen, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light source life, Network projection, OSD copy function, PC Free, Power on button, Quick Corner, Schedule Function, Screen Mirroring, Ultra-wide display (16:6), Web Control, Web Remote, Wireless LAN capable, iProjection App
Warranty period5 year(s)
Performance
Market positioningPresentation
Password protectionYes
Vertical scan range192 - 240 Hz
Noise level37 dB
Noise level (economic mode)27 dB
Heat dissipation895 BTU/h
Features
Password protectionYes
Noise level37 dB
Noise level (economic mode)27 dB
Country of originPhilippines
Multimedia
Built-in speaker(s)Yes
Number of built-in speakers1
RMS rated power16 W
Design
Market positioningPresentation
Product typeUltra short throw projector
Cable lock slot typeKensington
Product colourBlack
Cable lock slotYes
PlacementCeiling, Desktop, Wall
Display
Built-in displayNo
Power
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power sourceAC
Power consumption (typical)263 W
Power consumption (standby)0.5 W
Packaging data
Package width450 mm
Package depth485 mm
Package height320 mm
Package weight8.67 kg
Security
Cable lock slot typeKensington
Cable lock slotYes
Software
Bundled softwareEpson Creative Projection, EasyMP Multi PC Projection, Epson Classroom Connect, Epson Projector Content Manager, Epson Projector Management
Operational conditions
Operating relative humidity (H-H)20 - 80%
Storage temperature (T-T)-10 - 60 °C
Storage relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Weight & dimensions
Package width450 mm
Package depth485 mm
Package height320 mm
Weight5.9 kg
Width356 mm
Depth395 mm
Height133 mm
Package weight8.67 kg
Packaging content
Remote control includedYes
Quick start guideYes
ManualYes
Cables includedAC
Bundled softwareEpson Creative Projection, EasyMP Multi PC Projection, Epson Classroom Connect, Epson Projector Content Manager, Epson Projector Management
Batteries includedYes
Logistics data
Products per pallet12 pc(s)
Quantity per pack1 pc(s)
Pallet gross width80 cm
Pallet gross length120 cm
Pallet gross height2.07 m
Products per pallet layer (UK)4 pc(s)
Products per pallet layer2 pc(s)
Products per pallet (UK)24 pc(s)
Pallet length (UK)120 cm
Pallet height (UK)2.07 m
Other features
Supported network protocolsHTTPS, IPv6, SNMP, ESC/VP.net, PJLink
Security featuresKensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
InterfaceUSB 2.0-A (2x), USB 2.0, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, HDMI in (3x), Composite in, Miracast, Jack plug out, Jack plug in (3x), Wi-Fi Direct
F-number (relative aperture)1.6
Option typeAir filter, Ceiling mount, Connection and control box, External Speaker, Safety wire set, Visualiser camera, WP System - ELPWP10, Wall hanging bracket, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01
Control panel0.61 inch with C2 Fine
Box contentsPower cable, Quick Start Guide, Remote control incl. batteries, User guide, Warranty Documents
