| Projector |
|---|
| Number of colours | 1.07 billion colours |
| Projector native resolution | 1080p (1920x1080) |
| Projection distance (wide) | 0.9 - 8.9 m |
| Projection distance (tele) | 1.4 - 14.3 m |
| Native aspect ratio | 16:9 |
| Screen size compatibility | 787.4 - 7721.6 mm (31 - 304") |
| Projection distance | 0.88 - 14.29 m |
| Contrast ratio (typical) | 16000:1 |
| Contrast ratio (dynamic) | 16000:1 |
| Zoom ratio | 1:1.62 |
| Zoom capability | Yes |
| Projector brightness (economic mode) | 2300 ANSI lumens |
| Matrix size | 1.57 cm (0.62") |
| Keystone correction, vertical | ±30° |
| Keystone correction, horizontal | -30 - 30° |
| Projection technology | 3LCD |
| Projector brightness | 4100 ANSI lumens |
| Zoom type | Manual |
| Smart projector | No |
| Lamps |
|---|
| Lamp type | UHE |
| Lamp power | 230 W |
| Light source type | Lamp |
| Service life of light source | 6500 h |
| Service life of light source (economic mode) | 17000 h |
| Light source |
|---|
| Lamp type | UHE |
| Lamp power | 230 W |
| Light source type | Lamp |
| Service life of light source | 6500 h |
| Service life of light source (economic mode) | 17000 h |
| Lens system |
|---|
| Zoom ratio | 1:1.62 |
| Zoom capability | Yes |
| Focus | Manual |
| Focal length range | 18.2 - 29.1 mm |
| Aperture range (F-F) | 1.51 - 1.77 |
| Throw ratio | 1.30 - 2.09:1 |
| Zoom type | Manual |
| Video |
|---|
| Video processing | 10 bit |
| Video colour modes | Blackboard, Cinema, Dynamic, Presentation, sRGB |
| Analog signal format system | Not supported |
| Full HD | Yes |
| 3D | No |
| Audio |
|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 16 W |
| Ports & interfaces |
|---|
| VGA (D-Sub) ports quantity | 2 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Composite video in | 1 |
| Microphone in | Yes |
| Serial interface type | RS-232C |
| DVI port | No |
| AC (power) in | Yes |
| Service port type | USB Type-A |
| USB 2.0 Type-A ports quantity | 1 |
| Network |
|---|
| Smart TV | No |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet LAN (RJ-45) ports | 1 |
| Sound emission |
|---|
| Noise level | 37 dB |
| Noise level (economic mode) | 28 dB |
| Technical details |
|---|
| Product colour | White |
| HDCP | Yes |
| Security features | Kensington lock, Padlock, Security cable hole, Password protection |
| Option type | Air filter, Ceiling mount, Document camera, External Speaker, Safety wire set, Soft carry case, Spare lamp, Suspension adapter |
| Control panel | 0.62 inch with C2 Fine |
| Box contents | Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, User guide, Warranty document |
| Lamp power | 230 W |
| Products per pallet | 72 pc(s) |
| Quantity per pack | 1 pc(s) |
| Products per pallet layer (UK) | 6 pc(s) |
| Products per pallet layer | 6 pc(s) |
| Products per pallet (UK) | 72 pc(s) |
| Other features | A/V mute, AV Mute Slide, Auto Power On, Auto source search, Built-in speaker, Customizable user logo, Direct Power on/off, Document Camera Compatible, Home Screen, JPEG Viewer, Long lamp life, Microphone input, Network projection, OSD copy function, PC Free, Quick Corner, Schedule Function, Screen Mirroring, Split-Screen-Function, Volume control, Web Control, Web Remote, Wireless LAN capable, iProjection App |
| Performance |
|---|
| Market positioning | Presentation |
| Password protection | Yes |
| HDCP | Yes |
| Noise level | 37 dB |
| Noise level (economic mode) | 28 dB |
| Features |
|---|
| Interactive | No |
| Password protection | Yes |
| HDCP | Yes |
| Noise level | 37 dB |
| Noise level (economic mode) | 28 dB |
| Country of origin | Philippines |
| Multimedia |
|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 16 W |
| Design |
|---|
| Market positioning | Presentation |
| Cable lock slot type | Kensington |
| Product colour | White |
| Cable lock slot | Yes |
| Placement | Ceiling, Desktop |
| Display |
|---|
| Built-in display | No |
| Power |
|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power source | AC |
| Power consumption (typical) | 284 W |
| Power consumption (PowerSave) | 0.3 W |
| Power consumption (economy mode) | 181 W |
| Packaging data |
|---|
| Package width | 380 mm |
| Package depth | 390 mm |
| Package height | 175 mm |
| Package weight | 4.49 kg |
| Security |
|---|
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Operational conditions |
|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Weight & dimensions |
|---|
| Package width | 380 mm |
| Package depth | 390 mm |
| Package height | 175 mm |
| Weight | 3.1 kg |
| Width | 309 mm |
| Depth | 293 mm |
| Height | 105 mm |
| Package weight | 4.49 kg |
| Packaging content |
|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Logistics data |
|---|
| Products per pallet | 72 pc(s) |
| Quantity per pack | 1 pc(s) |
| Products per pallet layer (UK) | 6 pc(s) |
| Products per pallet layer | 6 pc(s) |
| Products per pallet (UK) | 72 pc(s) |
| Other features |
|---|
| Supported network protocols | HTTPS, IPv6, SNMP |
| Security features | Kensington lock, Padlock, Security cable hole, Password protection |
| Interface | USB 2.0-A, USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, HDMI in (2x), Composite in, Miracast, Jack plug out, Jack plug in, Cinch audio in, Microphone input, Apple AirPlay 2 |
| Option type | Air filter, Ceiling mount, Document camera, External Speaker, Safety wire set, Soft carry case, Spare lamp, Suspension adapter |
| Power consumption (economy mode) | 181 W |
| Control panel | 0.62 inch with C2 Fine |
| Box contents | Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, User guide, Warranty document |
