| Performance |
|---|
| Audio output channels | 2.0 channels |
| Audio input channels | 4.0 channels |
| Maximum video resolution | 1920 x 1080 pixels |
| Video compression formats | H.264, H.264+, H.265, H.265 Pro, H.265+ |
| Video capturing speed | 30 fps |
| Playback resolutions supported | 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Product colour | Black |
| Channels quantity | 16 channels |
| Audio formats supported | G.711 μ-law |
| Video streaming | Yes |
| Dual stream support | Yes |
| Bit rate | 64 Kbit/s |
| Audio streaming | Yes |
| Internal | No |
| Video |
|---|
| Maximum video resolution | 1920 x 1080 pixels |
| Video compression formats | H.264, H.264+, H.265, H.265 Pro, H.265+ |
| Video capturing speed | 30 fps |
| Playback resolutions supported | 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Bit rate | 64 Kbit/s |
| Ports & interfaces |
|---|
| Video input channels | 4 channels |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| VGA (D-Sub) output ports | 1 |
| USB 2.0 ports quantity | 2 |
| RS-485 ports | 1 |
| RS-232 ports | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| eSATA ports quantity | 1 |
| BNC input ports | 16 |
| Audio output | 3 |
| Audio input | 5 |
| Alarm output channels | 4 |
| Alarm input channels | 16 |
| Network |
|---|
| Ethernet LAN | Yes |
| Supported network protocols | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP |
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Hard drive |
|---|
| Number of HDDs supported | 4 |
| HDD interface | SATA III |
| HDD capacity | 12 TB |
| Power |
|---|
| Power consumption (typical) | 55 W |
| AC input voltage | 100 - 240 V |
| Weight & dimensions |
|---|
| Weight | 5 kg |
| Width | 445 mm |
| Depth | 390 mm |
| Height | 70 mm |
| Technical details |
|---|
| Video input channels | 4 channels |
| Ethernet LAN | Yes |
| Audio output channels | 2.0 channels |
| Audio input channels | 4.0 channels |
| Channels quantity | 16 channels |
| Audio formats supported | G.711 μ-law |
| AC input voltage | 100 - 240 V |
| Video streaming | Yes |
| Dual stream support | Yes |
| Audio streaming | Yes |
| Colour |
|---|
| Product colour | Black |
| Operational conditions |
|---|
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
