| Ports & interfaces |
|---|
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| Headphone connectivity | 3.5 mm |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| Headphone outputs | 1 |
| DC-in jack | Yes |
| Connectivity technology | Docking |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| DisplayPort version | 1.4 |
| HDCP | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Network |
|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance |
|---|
| Number of displays supported | 3 |
| On/off switch | Yes |
| Country of origin | Vietnam |
| Product colour | Black |
| Card reader integrated | No |
| Cable lock slot | Yes |
| Plug and Play | Yes |
| LED indicators | Yes |
| Data transfer rate | 10 Gbit/s |
| Cable lock slot type | Kensington, Nano |
| HD type | 4K Ultra HD |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Maximum refresh rate | 120 Hz |
| Technical details |
|---|
| Product colour | Black |
| Cable lock slot | Yes |
| Plug and Play | Yes |
| Data transfer rate | 10 Gbit/s |
| Sustainability compliance | Yes |
| Sustainability certificates | ErP |
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, VCCI |
| Special features | EQ |
| Products per master (outer) case | 6 pc(s) |
| Master (outer) case width | 260 mm |
| Master (outer) case gross weight | 7.5 kg |
| Master (outer) case length | 345 mm |
| Master (outer) case height | 220 mm |
| Storage |
|---|
| Card reader integrated | No |
| Power |
|---|
| Power source type | DC |
| Input current | 2.5 A |
| Compatible power plug types | EU, UK |
| AC input voltage | 100 - 240 V |
| Output voltage | 21 V |
| Output current | 7.1 A |
| Software |
|---|
| Windows operating systems supported | Yes |
| Indication |
|---|
| LED indicators | Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -18 - 60 °C |
| Operating relative humidity (H-H) | 0 - 55% |
| Sustainability |
|---|
| Sustainability compliance | Yes |
| Sustainability certificates | ErP |
| Weight & dimensions |
|---|
| Weight | 293 g |
| Width | 195 mm |
| Depth | 104 mm |
| Height | 36 mm |
| Package weight | 1.15 kg |
| Package width | 125 mm |
| Package depth | 245 mm |
| Package height | 100 mm |
| Design |
|---|
| Windows operating systems supported | Yes |
| Country of origin | Vietnam |
| Product colour | Black |
| Cable lock slot | Yes |
| LED indicators | Yes |
| Cable lock slot type | Kensington, Nano |
| Packaging data |
|---|
| Quantity per pack | 1 pc(s) |
| Package weight | 1.15 kg |
| Package width | 125 mm |
| Package depth | 245 mm |
| Package height | 100 mm |
| Packaging content |
|---|
| Quick start guide | Yes |
| Cables included | AC |
| AC adapter included | Yes |
| Warranty card | Yes |
| Quantity per pack | 1 pc(s) |
| Logistics data |
|---|
| Products per master (outer) case | 6 pc(s) |
| Master (outer) case width | 260 mm |
| Master (outer) case gross weight | 7.5 kg |
| Master (outer) case length | 345 mm |
| Master (outer) case height | 220 mm |
| Other features |
|---|
| USB ports quantity | 5 |
| Minimum system requirements | CPU: Intel Core i5 6th generation or above Memory: 8Gb or above GPU: Intel HD Graphics 620 or above |
| Compatible operating systems | Windows 10 or above |
| Special features | EQ |
