| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Microphone in | No |
| Headphone outputs | 0 |
| Connectivity technology | Wired |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.2 |
| USB Power Delivery up to | 140 W |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB 2.0 Type-C ports quantity | 1 |
| Network |
|---|
| Full duplex | Yes |
| Wake-on-LAN ready | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100,10,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance |
|---|
| UASP support | Yes |
| Maximum digital resolution | 3480 x 2160 pixels |
| Full duplex | Yes |
| Number of displays supported | 1 |
| Product colour | Grey |
| Card reader integrated | Yes |
| LED indicators | Network |
| Data transfer rate | 10 Gbit/s |
| Compatible memory cards | MicroSD (TransFlash), SD |
| HD type | 4K Ultra HD |
| Housing material | Aluminium |
| Mean time between failures (MTBF) | 31195 h |
| Technical details |
|---|
| Product colour | Grey |
| Data transfer rate | 10 Gbit/s |
| Compliance certificates | Federal Communications Commission (FCC), RoHS |
| User guide | Yes |
| Products per master (outer) case | 60 pc(s) |
| Master (outer) case width | 530 mm |
| Master (outer) case length | 330 mm |
| Master (outer) case height | 310 mm |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Power |
|---|
| Output voltage | 5 V |
| USB cable length | 0.203 m |
| Software |
|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 8.1 |
| Mac operating systems supported | Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia, Mac OS 26 Tahoe |
| Linux operating systems supported | Ubuntu 20.04 LTS, Ubuntu 22.04, Ubuntu 22.04 LTS, Ubuntu 24.04 LTS |
| Mobile operating systems supported | iPadOS, iOS |
| Indication |
|---|
| LED indicators | Network |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 32 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 5 - 85% |
| Weight & dimensions |
|---|
| Weight | 100 g |
| Width | 59 mm |
| Depth | 115 mm |
| Height | 14 mm |
| Package weight | 187 g |
| Package width | 190 mm |
| Package depth | 110 mm |
| Package height | 19 mm |
| Design |
|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 8.1 |
| Mac operating systems supported | Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia, Mac OS 26 Tahoe |
| Product colour | Grey |
| LED indicators | Network |
| Packaging data |
|---|
| Package weight | 187 g |
| Package width | 190 mm |
| Package depth | 110 mm |
| Package height | 19 mm |
| Packaging content |
|---|
| User guide | Yes |
| Logistics data |
|---|
| Products per master (outer) case | 60 pc(s) |
| Master (outer) case width | 530 mm |
| Master (outer) case length | 330 mm |
| Master (outer) case height | 310 mm |
| Other features |
|---|
| Chipset | Parade - PS188, VIA - VL822, Genesys Logic - GL3231S, Realtek - RTL8153E |
