| Design |
|---|
| Colour name | Volt Green |
| Product type | Laptop |
| Market positioning | Gaming |
| Housing material | Aluminium |
| Form factor | Clamshell |
| Product colour | Grey, Green |
| Display back cover material | Plastic |
| Display |
|---|
| HD type | 2.5K |
| Panel type | IPS-Level |
| Display response rise/fall | 3 ms |
| Touchscreen | No |
| Display resolution | 2560 x 1600 pixels |
| Display diagonal | 40.6 cm (16") |
| Anti-glare screen | Yes |
| Maximum refresh rate | 300 Hz |
| RGB colour space | DCI-P3 |
| Colour gamut | 100% |
| Native aspect ratio | 16:10 |
| Processor |
|---|
| Processor generation | Intel Core Ultra (Series 2) |
| Processor cache type | Smart Cache |
| Processor cache | 36 MB |
| Processor model | 290HX Plus |
| Processor boost frequency | 5.5 GHz |
| Processor cores | 24 |
| Processor threads | 24 |
| Processor socket | BGA 2114 |
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 9 |
| Processor base power | 55 W |
| Maximum turbo power | 160 W |
| Efficient-core base frequency | 1.8 GHz |
| Performance-core base frequency | 2.7 GHz |
| Efficient-core Max Turbo Frequency | 4.7 GHz |
| Performance-core Max Turbo Frequency | 5.5 GHz |
| Performance cores | 8 |
| Efficient cores | 16 |
| Low Power Efficient-cores | 0 |
| Neural processor unit (NPU) |
|---|
| Neural processor unit (NPU) | Intel AI Boost |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to | 36 TOPs |
| NPU performance up to | 13 TOPs |
| GPU performance up to | 8 TOPs |
| Memory |
|---|
| Memory form factor | SO-DIMM |
| Internal memory | 32 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 5600 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 64 GB |
| Memory channels | Dual-channel |
| Storage |
|---|
| SSD form factor | M.2 |
| Storage media | SSD |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| Total storage capacity | 1 TB |
| Total SSDs capacity | 1 TB |
| NVMe | Yes |
| Graphics |
|---|
| Discrete graphics card | Yes |
| Discrete graphics card memory | 8 GB |
| NVIDIA G-SYNC | Yes |
| On-board graphics card family | Intel® Graphics |
| On-board graphics card | Yes |
| On-board graphics card model | Intel® Graphics |
| Discrete graphics card model | NVIDIA® GeForce RTX™ 5070 Laptop GPU |
| Discrete graphics memory type | GDDR7 |
| Discrete GPU manufacturer | NVIDIA |
| On-board GPU manufacturer | Intel |
| Audio |
|---|
| Audio system | Dolby Atmos |
| Number of built-in speakers | 2 |
| Built-in microphone | Yes |
| Camera |
|---|
| Front camera | Yes |
| Front camera HD type | Full HD |
| Infrared (IR) camera | Yes |
| Windows Hello | Yes |
| Optical drive |
|---|
| Optical drive type | No |
| Network |
|---|
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| Antenna type | 2x2 |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB 2.0 ports quantity | 0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| USB Power Delivery (USB PD) | Yes |
| Thunderbolt 4 ports quantity | 1 |
| Intel® Thunderbolt 4 | Yes |
| Keyboard |
|---|
| Pointing device | Touchpad |
| Numeric keypad | No |
| Keyboard backlit | Yes |
| Keyboard backlit colour | RGB |
| Keyboard backlit zone | Per-key RGB |
| Copilot key | Yes |
| Software |
|---|
| Operating system architecture | 64-bit |
| Bundled software | Xbox Game Pass Premium_2 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass Premium. Eligible markets are determined at activation. Game catalog varies by region, device, and time.) 3-Month Google AI Pro Subscription 6-Month Dropbox 500GB Subscription 1-Year ASUS Secure Auto-Backup 200GB Subscription *Available in eligible markets only. Eligibility varies by region, device, and time. Terms and conditions apply. See promotion pages for details. |
| Trial software | 1-month trial for new Microsoft 365 customers. Credit card required. McAfee® 30 days free trial |
| Operating system installed | Windows 11 Home |
| Microsoft Copilot | Yes |
| Technical details |
|---|
| Market positioning | Gaming |
| Housing material | Aluminium |
| Form factor | Clamshell |
| Product colour | Grey, Green |
| Discrete graphics card memory | 8 GB |
| Battery |
|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
| Battery capacity | 90 Wh |
| Power |
|---|
| AC adapter power | 280 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 14 A |
| AC adapter output voltage | 20 V |
| USB Power Delivery (USB PD) | Yes |
| USB Type-C charging port | Yes |
| USB Type-C required charging power (min) | 45 W |
| USB Type-C required charging power (max) | 100 W |
| Security |
|---|
| Password protection | Yes |
| Trusted Platform Module (TPM) | Yes |
| Password protection type | BIOS, User |
| Windows Hello | Yes |
| Weight & dimensions |
|---|
| Width | 354 mm |
| Depth | 268 mm |
| Height (front) | 2.28 cm |
| Height (rear) | 3.08 cm |
| Weight | 2.65 kg |
| Packaging data |
|---|
| AC adapter included | Yes |
| Packaging content |
|---|
| AC adapter included | Yes |
| Other features |
|---|
| On-board graphics card | Yes |
| Audio system | Dolby Atmos |
| AC adapter included | Yes |
| Anti-glare screen | Yes |
