| Management features |
|---|
| Switch type | Managed |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L3 |
| Ports & interfaces |
|---|
| SFP+ module slots quantity | 4 |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Console port | RJ-45 |
| I/O ports | 48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: Ports 1-48 support 10BASE-T/100BASE-TX, 1000BASE-T (full only); 4 SFP+ 1000/10000 SFP+ ports; 1 RJ-45 serial console port |
| Network |
|---|
| Auto-sensing | Yes |
| Networking standards | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Full duplex | Yes |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Link aggregation | Yes |
| IP routing | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | Yes |
| IGMP snooping | Yes |
| IPv6 FIB entries | 256 |
| IPv4 FIB entries | 512 |
| Data transmission |
|---|
| Throughput | 131 Mpps |
| Latency (1 Gbps) | 5 µs |
| Latency (10 Gbps) | 3 µs |
| MAC address table | 16384 entries |
| Switching capacity | 176 Gbit/s |
| Jumbo frames support | Yes |
| Security |
|---|
| Authentication | MAC-based authentication |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Authentication type | HWTACACS, RADIUS |
| DHCP features | DHCP server |
| Multicast features |
|---|
| Multicast support | Yes |
| Protocols |
|---|
| Routing protocols | OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2 |
| IPv6 FIB entries | 256 |
| IPv4 FIB entries | 512 |
| Design |
|---|
| Form factor | 1U |
| Stackable | Yes |
| Rack mounting | Yes |
| Performance |
|---|
| Physical stacking (units) | 9 |
| Memory type | SDRAM |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| Stackable | Yes |
| Harmonized System (HS) code | 85176990 |
| Power |
|---|
| Power consumption (max) | 478 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| DC input voltage | 54 - 57 V |
| Power consumption note | 478W (Maximum), 47W (Idle) Notes: Idle power is the actual power consumption of the device with no ports connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE power is the power supplied by the internal power supply. When supplemented with the use of an HPE RPS1600, up to 740W of PoE+ can be supplied. Maximum current rating for DC power is 25A. AC input power is 47W typical and 490W maximum (including 370W PoE+ consumption). DC input voltage range is –54 VDC to –57 VDC. Total DC input power is 43W typical and 890W with 800W PoE+ power consumption. DC input voltage range is –54 VDC to –57 VDC. DC input source is the HPE RPS1600. |
| Power source | AC |
| Power supply note | At least 1 power supply is required (not included, must be ordered separately) |
| Power over Ethernet (PoE) |
|---|
| Total Power over Ethernet (PoE) budget | 370 W |
| Power over Ethernet (PoE) | Yes |
| Other features |
|---|
| Latency | 1000 Mb latency: < 5 µs 10 Gbps latency: < 3 µs |
| Performance management | HPE Aruba Networking IMC - Intelligent Management Center; SmartMC; Command-line interface; Web browser; SNMP manager |
| Memory and processor | 512 MB SDRAM, 256 MB flash |
| Weight (imperial) | 6 kg (13.2 lbs) |
| I/O ports | 48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: Ports 1-48 support 10BASE-T/100BASE-TX, 1000BASE-T (full only); 4 SFP+ 1000/10000 SFP+ ports; 1 RJ-45 serial console port |
| Dimensions (W x D x H) (imperial) | 43.7 x 439.9 x 399.8 mm (1.72 x 17.3 x 15.7") |
| Operational conditions |
|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 1671 BTU/h |
| Virtual LAN features |
|---|
| VLAN support | Yes |
| Weight & dimensions |
|---|
| Width | 43.6 mm |
| Depth | 440 mm |
| Height | 400 mm |
| Weight | 6 kg |
| Weight (imperial) | 6 kg (13.2 lbs) |
| Dimensions (W x D x H) (imperial) | 43.7 x 439.9 x 399.8 mm (1.72 x 17.3 x 15.7") |
| IPv4 & IPv6 features |
|---|
| IPv6 FIB entries | 256 |
| IPv4 FIB entries | 512 |
| Technical details |
|---|
| Physical stacking (units) | 9 |
| Form factor | 1U |
| Stackable | Yes |
| Rack mounting | Yes |
| Memory |
|---|
| Memory type | SDRAM |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| Logistics data |
|---|
| Harmonized System (HS) code | 85176990 |
