SKU: S5E30A  |   Brand: HPE

HPE Networking Instant On Switch 48p Gigabit 4p SFP 1840

SKU: S5E30A  |   Brand: HPE

HPE Networking Instant On Switch 48p Gigabit 4p SFP 1840

0 in stock

£270.23 ex. VAT

Figures are exclusive of VAT.



HPE Networking Instant On Switch Series 1840 is an entry-level, smart-managed Layer 2 Gigabit switch series for small and medium-sized businesses that need reliable, secure, and cost-effective 1G wired connectivity. Available in 8-, 24-, and 48-port models with PoE and non-PoE options, it combines intuitive management with enterprise-grade security. Using the mobile app, Instant On Cloud Portal, or local web GUI, businesses can quickly deploy, monitor, and manage their network without subscription fees. Built-in features such as ACLs, IEEE 802.1X, VLANs, DHCP snooping, IP Source Guard, and TPM 2.0 help protect business operations, while select PoE models provide up to 370W to power access points, cameras, and phones.

What is new supporting point:
Easy setup and management through the mobile app, cloud web portal, or local web GUI with no subscription or licensing fees
Built-in security features such as VLANs, IEEE 802.1X, ACLs, and loop protection help safeguard business networks
Class 4 PoE models provide budget options up to 370W to power access points, IP phones, and surveillance cameras
Dedicated 1G SFP uplinks on select 24- and 48-port models extend connectivity and support fiber uplinks
Select models feature fanless design for quiet, energy-efficient deployment in offices, retail spaces, and other noise-sensitive environments

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 46 to 48
Switch type Managed
Power over Ethernet (PoE) N
Rack mounting Y
Weight 5,860.00kg

Management features
Switch typeManaged
Web-based managementYes
Switch layerL2
Ports & interfaces
SFP module slots quantity4
Basic switching RJ-45 Ethernet ports quantity48
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
I/O ports48x RJ-45 autosensing 10M/100M/1G ports 4x SFP 1GbE ports
Network
Networking standardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
VLAN supportYes
Link aggregationYes
10G supportNo
IGMP snoopingYes
Data transmission
Throughput77.37 Mpps
Latency (1 Gbps)3.3 µs
Packet buffer memory4 MB
MAC address table16000 entries
Switching capacity104 Gbit/s
Jumbo frames supportYes
Security
SSH/SSL supportYes
IGMP snoopingYes
Access Control List (ACL)Yes
Protocols
Management protocolsSNMP
Design
Product colourWhite
Rack mountingYes
Performance
Processor frequency1200 MHz
Memory typeDDR4-SDRAM
Internal memory1000 MB
Flash memory512 MB
Processor manufacturerARM
Built-in processorYes
Processor modelARM Cortex-A9
Packet buffer memory4 MB
Power
Power consumption (max)38.8 W
Power supply includedYes
AC input voltage200 - 240 V
AC input frequency50/60 Hz
Power consumption note[100% traffic] 100–127V: 38.8W | 200–220V: 38.5W [Idle] 100–127V: 19.8W | 200–220V: 19.8W
Power sourceAC
Power supply noteInternal
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Other features
Latency[LIFO] 100 Mb: <8.0 μSec 1000 Mb: <3.3 μSec
Performance managementHPE Networking Instant On Cloud; Web browser; SNMP manager
Memory and processorArm Cortex–A9 @ 1.2 GHz, 1GB SDRAM, 512MB Flash, 4MB packet buffer
Fan1 non-field-replaceable fan, left-to-right airflow
Weight (imperial)5.86 kg (12.9 lbs)
I/O ports48x RJ-45 autosensing 10M/100M/1G ports 4x SFP 1GbE ports
Dimensions (W x D x H) (imperial)575.1 x 507.2 x 125.2 mm (22.6 x 20 x 4.93")
Operational conditions
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)15 - 95%
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)15 - 95%
Operating altitude0 - 3000 m
Heat dissipation132.3 BTU/h
Virtual LAN features
VLAN supportYes
Weight & dimensions
Width575.1 mm
Depth507.2 mm
Height125.2 mm
Weight5.86 kg
Weight (imperial)5.86 kg (12.9 lbs)
Dimensions (W x D x H) (imperial)575.1 x 507.2 x 125.2 mm (22.6 x 20 x 4.93")
Technical details
Product colourWhite
Processor frequency1200 MHz
Rack mountingYes
Built-in processorYes
Memory
Packet buffer memory4 MB
Memory typeDDR4-SDRAM
Internal memory1000 MB
Flash memory512 MB
