| Performance |
|---|
| Video input channels | 16 channels |
| Alarm input channels | 4 |
| Alarm output channels | 1 |
| Maximum resolution | 3840 x 2160 pixels |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Supported network protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Audio formats supported | AAC, G.711 A-law, G.711 μ-law, G.722, G.726 |
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
| Maximum frame rate | 30 fps |
| Supported resolutions | 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Face detection | Yes |
| Number of simultaneously playbacked channels | 16 channels |
| Output bandwidth | 160 Mbit/s |
| Input bandwidth | 160 Mbit/s |
| Wireless LAN features |
|---|
| Wi-Fi | No |
| Hard drive |
|---|
| Number of HDDs supported | 2 |
| Maximum storage capacity | 20 TB |
| HDD interface | SATA |
| Number of HDDs installed | 0 |
| HDD capacity | 10 TB |
| Storage |
|---|
| Number of HDDs supported | 2 |
| Maximum storage capacity | 20 TB |
| HDD interface | SATA |
| Number of HDDs installed | 0 |
| HDD capacity | 10 TB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 17 |
| Power over Ethernet (PoE) | Yes |
| VGA (D-Sub) output ports | 1 |
| HDMI output | Yes |
| USB 2.0 ports quantity | 2 |
| Supported network protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Audio RCA inputs | 1 |
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
| Audio RCA outputs | 1 |
| Power over Ethernet (PoE) ports quantity | 16 |
| Internal SATA ports quantity | 2 |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| HDMI ports quantity | 1 |
| Features |
|---|
| Rack mounting | Yes |
| Rack capacity | 1U |
| Product colour | Black |
| Power |
|---|
| Power consumption (typical) | 15 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Total Power over Ethernet (PoE) budget | 200 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Technical details |
|---|
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Weight & dimensions |
|---|
| Width | 385 mm |
| Depth | 315 mm |
| Height | 52 mm |
| Weight | 3 kg |
