| Performance |
|---|
| Video input channels | 32 channels |
| Alarm input channels | 16 |
| Alarm output channels | 9 |
| Maximum resolution | 7680 x 4320 pixels |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Supported network protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Audio formats supported | AAC, G.711 A-law, G.711 μ-law, G.722, G.726, MP2L2 |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Maximum frame rate | 60 fps |
| Supported resolutions | 7680 x 4320, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768 |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Video recording modes | 720p, 1080p, 2160p, 4320p |
| Output bandwidth | 400 Mbit/s |
| Input bandwidth | 320 Mbit/s |
| Wireless LAN features |
|---|
| Wi-Fi | No |
| Hard drive |
|---|
| Number of HDDs supported | 4 |
| HDD interface | SATA |
| Storage |
|---|
| Number of HDDs supported | 4 |
| HDD interface | SATA |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 24 |
| Power over Ethernet (PoE) | Yes |
| BNC video output | Yes |
| HDMI output | Yes |
| USB 2.0 ports quantity | 2 |
| Supported network protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| RS-485 ports | 2 |
| RS-232 interface | Yes |
| eSATA | Yes |
| Audio RCA inputs | 1 |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Audio RCA outputs | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Power over Ethernet (PoE) ports quantity | 24 |
| eSATA ports quantity | 1 |
| RS-232 ports | 1 |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| HDMI ports quantity | 2 |
| Features |
|---|
| Rack mounting | Yes |
| LED indicators | Yes |
| Certification | CE, REACH, WEEE, FCC, CB, RCM, KC, UL |
| Rack capacity | 1.5U |
| Product colour | Black, Grey |
| Brand compatibility | Hikvision Digital Technology |
| Power |
|---|
| Power consumption (typical) | 15 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operational conditions |
|---|
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions |
|---|
| Width | 445 mm |
| Depth | 400 mm |
| Height | 75 mm |
| Weight | 5 kg |
| Packaging content |
|---|
| Quick installation guide | Yes |
