Teleproject UK


SKU: 90MS02X1-M001Y0  |   Brand: ASUS

ASUS Chromebox CHROMEBOX5-S7009UNA Intel® Core™ i7 i7-1355U 16 GB DDR4-SDRAM 256 GB SSD ChromeOS Mini PC Black

SKU: 90MS02X1-M001Y0  |   Brand: ASUS

ASUS Chromebox CHROMEBOX5-S7009UNA Intel® Core™ i7 i7-1355U 16 GB DDR4-SDRAM 256 GB SSD ChromeOS Mini PC Black

33 in stock

£617.74 ex. VAT

Figures are exclusive of VAT.



ASUS Chromebox 5a delivers performance and responsiveness to empower users with incredible productivity.

Performance for any workplace
ASUS Chromebox 5a delivers performance and responsiveness to empower users with incredible productivity

On-board graphics card Y
Operating system installed ChromeOS
Display included N
Processor family Intel Core i7
Optical drive type N
Discrete graphics card N
Product type Mini PC (<= 3L)
Total storage capacity 100GB to 300GB
Internal memory 16GB
Family Chromebox
Weight 2.00kg

Processor
Processor generation13th gen Intel® Core™ i7
Processor cache typeSmart Cache
Processor cache12 MB
Processor modeli7-1355U
Number of processors installed1
Processor manufacturerIntel
Processor boost frequency5 GHz
Processor threads12
Processor cores10
Processor familyIntel® Core™ i7
Performance cores2
Efficient cores8
Processor base power15 W
Maximum turbo power55 W
Efficient-core Max Turbo Frequency3.7 GHz
Performance-core Max Turbo Frequency5 GHz
Memory
Internal memory16 GB
Maximum internal memory32 GB
Memory slots2x SO-DIMM
Internal memory typeDDR4-SDRAM
Storage
Storage mediaSSD
Optical drive typeNo
SSD interfacePCI Express 4.0
SSD capacity256 GB
Number of SSDs installed1
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Total storage capacity256 GB
SSD form factorM.2
Total SSDs capacity256 GB
NVMeYes
M.2 SSD size2280 (22 x 80 mm)
Graphics
Discrete graphics cardNo
On-board graphics card familyIntel Iris Xe Graphics
On-board graphics cardYes
Discrete graphics card modelNot available
On-board graphics card modelIntel Iris Xe Graphics
On-board GPU manufacturerIntel
Optical drive
Optical drive typeNo
Network
Ethernet LANYes
Wi-FiYes
BluetoothYes
Bluetooth version5.3
Wi-Fi standardsWi-Fi 6E (802.11ax)
Ethernet LAN data rates10,100,1000 Mbit/s
Cabling technology10/100/1000Base-T(X)
Top Wi-Fi standardWi-Fi 6E (802.11ax)
Ports & interfaces
Combo headphone/mic portYes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Thunderbolt 3 ports quantity0
HDMI version2.1
USB 2.0 ports quantity0
HDMI ports quantity2
Ethernet LAN (RJ-45) ports1
DisplayPorts quantity1
DC-in jackYes
DisplayPort version1.4
USB Type-C DisplayPort Alternate ModeYes
Technical details
Product typeMini PC
Product colourBlack
Chassis typeMini PC
Design
Product colourBlack
Chassis typeMini PC
Performance
Product typeMini PC
Software
Operating system installedChromeOS
Power
Power supply90 W
Certificates
CertificationBSMI/CB/CE/FCC/UL/Energy Star/C-Tick/WiFi/RF/VCCI
Weight & dimensions
Package width334 mm
Package depth206 mm
Package height69 mm
Width166.5 mm
Depth165.8 mm
Height45.9 mm
Package weight1.8 kg
Weight800 g
Packaging data
Package width334 mm
Package depth206 mm
Package height69 mm
Package weight1.8 kg
Packaging content
Display includedNo
Display
Display includedNo
Other features
On-board graphics cardYes
Processor manufacturerIntel
